1 1/2 IN Lead Free Water Pressure Reducing Valve Double Union NPT Female SS Seat Gauge Tapping High Range 75-125 psi
1 1/2 IN Lead Free Water Pressure Reducing Valve Double Union NPT Female SS Seat Gauge Tapping High Range 75-125 psi
1 1/2 IN Lead Free Water Pressure Reducing Valve Double Union NPT Female SS Seat Gauge Tapping High Range 75-125 psi
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$3,572.00Â /Â ea
Out of Stock
- Attributes
- Features & Benefits
- Documents
- Marketing Information
Attributes
BrandWATTS®
Adjustable Reduced Pressure Range Psi75.4 to 125
Depth13"
Disc MaterialEPDM
Height8.5"
High Pressure Reduced Pressure Range75 to 125 psi
High Pressure Reduced Pressure Setting90 psi
IndustryPlumbing
Inlet Connection Size1-1/2"
Inlet Connection TypeUnion Joint
Inlet Thread TypeNPT
MaterialLead Free Copper Silicon Alloy
Maximum Temperature Deg F180
Maximum Working Pressure Psi300
Minimum Temperature Deg F33
Outlet Connection Size1-1/2"
Outlet Connection Thread TypeNPT
Outlet Connection TypeUnion Joint
Prop 65 WarningYes
Seat MaterialStainless Steel
SeriesLF25AUB-Z3
Standard Reduced Pressure Setting Psi50
StrainerYes
Strainer MaterialStainless Steel
Thermal Expansion BypassYes
Valve StyleStandard
Weight13.5 lbs.
Width5.88"
Shipping Dimensions (L x W x H)13" x 5.88" x 8.5"
Features & Benefits
- Sealed spring cage with stainless steel cage screws
- Integral stainless steel strainer removable for cleaning
- Replaceable seat
- Gauge port tapping allows downstream pressure measurements
Documents
Marketing Information
This 1 1/2 inch lead free brass water pressure reducing valve is designed to reduce incoming water pressure to protect plumbing systems and reduce water consumption for commercial, industrial, and residential applications. The easy maintenance assembly consists of a replaceable seat module, NPT threaded union inlet and outlet conections, stainless steel strainer, a thermal expansion bypass, and a gauge port tapping furnished with a pipe plug. The temperature range is 33 to 180 degrees F (0.5 to 82 degrees C). Suitable for up to 300 psi (20.7 bar), the pressure range can be adjusted from 75 to 125 psi (5.2 to 8.6 bar).
1 1/2 IN Lead Free Water Pressure Reducing Valve Double Union NPT Female SS Seat Gauge Tapping High Range 75-125 psi
BrandWATTS®
MFG #0009400
Keller #1188283
