Bell & Gossett ecocirc® XL Series ecocirc® XL N 36-45 104452LF High-Efficiency Wet Rotor Circulator Pump, 60 cu-m/hr
Bell & Gossett ecocirc® XL Series ecocirc® XL N 36-45 104452LF High-Efficiency Wet Rotor Circulator Pump, 60 cu-m/hr
Bell & Gossett High-Efficiency Wet Rotor Circulator Pump, ecocirc® XL Series, Model: ecocirc® XL N 36-45, 60 cu-m/hr Flow Rate, 13 m Maximum Head, 20 to 150 W, 208-230 V, 0.1 to 1.5 A, 50/60 Hz, 175 psi Maximum Pressure, 1/6 hp, 1 ph Phase, 14 to 230 deg F, NEMA 2, IP44 Enclosure, Sleeve Bearing, Stainless Steel, 6.38 in H x 7.2 in W x 9.94 in D, Additional Information: ECM/Permanent Magnet Motor, Class F Insulation, EPDM Gasket/O-ring, Polyphenylene Sulfide Impeller
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$4,197.92 / ea
Out of Stock
- Attributes
- Additional Information
- Features & Benefits
- Documents
- Marketing Information
Attributes
BrandBell & Gossett
Additional InformationECM/Permanent Magnet Motor, Class F Insulation, EPDM Gasket/O-ring, Polyphenylene Sulfide Impeller
Amperage Rating0.1 to 1.5
Bearing TypeSleeve
Dimensions6.38 " H x 7.2 " W x 9.94 " D
Enclosure TypeNEMA 2, IP44
Flow Rate60
Frequency Rating50/60
HP Rating1/6
MaterialStainless Steel
Maximum Head13
Maximum Pressure175
ModelEcocirc XL N 36-45
Phase1
Power Rating20 to 150
Seriesecocirc XL Series
Temperature Rating14 to 230
Voltage Rating208-230
Additional Information
cUL C22.2 File No. 108|NSF/ANSI 372|UL 778/1004-1/1004-7/60730-1|CSA Certified
Features & Benefits
- High efficiency Different operation modes adopted to all real life situations Automatic proportional pressure control (Delta pv) Constant pressure control (Delta pc) Differential temperature control (Delta pT) Manual set constant speed Night setback mode Easy to install and start up, no advanced programming necessary Clear display and easy setting with touch buttons For hot and cold media including tap hot water, geothermal and solar systems Communicate with Modbus RTU and BACnet systems Can be controlled from a laptop, tablet or smartphone via WiFi
Documents
Marketing Information
The new Lowara ecocirc XL and XLplus are the wet rotor circulators that provide state-of-the-art technology in hydraulics, motors and intelligent controls. The ecocirc XL and XLplus are everything you need in a large wet rotor circulator and nothing you don't. The purposefully engineered, easy-to-install ecocirc XL and XLplus are designed with simplicity and efficiency in mind.
