Rheem® Ovation Series RACL2090CAZ Commercial Split Air Conditioner, 7.5 ton, 208-230 V
Rheem® Ovation Series RACL2090CAZ Commercial Split Air Conditioner, 7.5 ton, 208-230 V
Rheem® Commercial Split Air Conditioner, Classic® RACL Series, 7.5 ton Nominal Capacity, 208-230 V Voltage Rating, 38 A Amperage Rating, 60 Hz Frequency Rating, 3 ph Phase, Scroll Compressor Type, 5700 cfm Rating, 11.2 EER Rating, 2 Number of Stages, R-410A Refrigerant Type, 2-Row Coil Rating, 60 A Fuse Rating, 32.44 sq-ft Face Area, Condenser Motor Type, 550 psig, Steel, Galvanized, 50 in H x 35-3/4 in W x 35-3/4 in D Dimensions, 1 Number of Compressors, 1 Number of Fans Additional Information
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$10,707.31 / ea
Out of Stock
- Attributes
- Additional Information
- Features & Benefits
- Documents
Attributes
BrandRheem®
Additional Information1 Number of Compressors, 1 Number of Fans
Amperage Rating38
CFM Rating5700
Coil Rating2-Row
Compressor TypeScroll
Dimensions50 " H x 35-3/4 " W x 35-3/4 " D
EER Rating11.2
Face Area32.44
FinishGalvanized
Frequency Rating60
Fuse Rating60
IndustryHVAC
MaterialSteel
Motor TypeCondenser
Nominal Capacity7.5
Number of Stages2
Phase3
Pressure Rating550
Refrigerant TypeR-410A
SeriesClassic RACL Series
Voltage Rating208-230
Warranty5 Year Compressor, 1 Year Parts
Additional Information
AHRI Certified|cULus Listed
Features & Benefits
- Cabinet - all access panels can be opened or removed without affecting the structural strength of the unit, stamped louvered panels offer 100% protection for the condenser coil Equipment ground - lug for field connection of ground wire Contactor - the contactor is an electrical switch which operates the compressor and outdoor fans, its 24 V coil is activated on a call for cooling or heating Transformer - 75 VA Step down type, from line to 24 V with resettable circuit breaker Auto reset high pressure control and auto reset low pressure control - to provide compressor protection under abnormally high head pressure conditions (outdoor fan failure, restriction, dirty coil and more) or abnormally low suction pressure conditions (restrictions, TEV failure, loss of charge, indoor blower failure and more) while eliminating nuisance tripping sometimes experienced with conventional control systems Coil - constructed with copper tubes and aluminum fins mechanically bonded to tubes for maximum heat transfer capabilities, all coil assemblies are leak tested up to 550 psig (3792 kPa) internal pressure Service access - control box with separate line and control voltages, as well as compressor and other refrigerant controls are accessible through access panels, an electrical access cover may be opened or removed without affecting normal operation of the unit, condenser fan motors are equipped with molded plugs for easy removal, louver panels and end access panel can be removed for coil cleaning Base pan - galvanized steel with weather-resistant baked enamel finish Compressor - the scroll compressor is hermetically sealed with internal high temperature protection and durable insulation on motor windings, the entire compressor is mounted on rubber grommets to reduce vibration and noise Suction line accumulator - to prevent liquid slugging of compressor Refrigerant connections - all field sweat joints are made external of the unit and are located close to the ground for a neat looking installation Service valves - standard on liquid line and vapor line
