ADA Compliant|CSA B651|ICC/ANSI A117.1|OBC Certified

• Soap dispensing volume can be adjusted to 0.8 mL, 1.2 mL, 1.6 mL, or 2.0 mL 54 oz (1600 mL) high-capacity soap reservoir Optional 27 oz. (800 ml) low-capacity soap reservoir (sold separately) Sensor range adjustable from 1" to 4" (25 to 101 mm). Default set at approximately 2-3/4" (69 mm) Low soap above-the-counter indicator Maintenance/cleaning mode is activated for 30 seconds when sensor is blocked for 10 seconds Vandal-resistant sensor delays dispensing for twenty seconds if activated 4 times in under 5 seconds Low soap and low battery above-the-counter indicators Easy below-the-counter refill AC-powered operation-no batteries to replace Requires low (1-20 cps or gr/m-s) viscosity foam soap with no suspended particles. Please see Installation Guide or Maintenance and Use Guide for specific soap recommendations KOHLER® soap (sold separately) recommended for optimized performance and longevity Requires K-13480 single or K-13481 multiple AC adapter unit (sold separately)

This Composed® 54-ounce high-capacity touchless foaming soap dispenser is ready to tackle high-traffic applications. With solid-brass construction, this AC-powered dispenser is equipped with an above-the-counter light to let you know when soap supply is low. Vandal-resistant sensor prevents soap waste.
