Grundfos 99918282 Centrifugal Pump, 10 hp, 3 ph, 208 to 230/460 V, 4 in Inlet Connection, 339 gpm
Grundfos 99918282 Centrifugal Pump, 10 hp, 3 ph, 208 to 230/460 V, 4 in Inlet Connection, 339 gpm
Grundfos Centrifugal Pump, Model: CR 64-1-1, 208 to 230/460 V, Amperage Rating: 25.4 to 23/11.5 A, 60 Hz Frequency, HP Rating: 10 hp, Phase: 3 ph, 4 in Inlet Connection, Outlet Connection Size: 4 in, 339 gpm Flow Rate, Maximum Pressure: 232.06 psi, Maximum Head: 105 ft, 3467 rpm Speed, Motor Type: WEG, Service Factor: 1.15, -22 to 248 deg F, 13 in Overall Width
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$8,963.00Â /Â ea
Out of Stock
- Attributes
- Additional Information
- Features & Benefits
- Documents
- Marketing Information
Attributes
BrandGrundfos
Amperage Rating25.4 to 23/11.5
Flow Rate339
Frequency Rating60
HP Rating10
IndustryHydronics
Inlet Connection Size4
Maximum Head105
Maximum Pressure232.06
ModelCR 64-1-1
Motor TypeWEG
Outlet Connection Size4
Overall Width13
Phase3
Service Factor1.15
Speed Rating3467
Temperature Rating-22 to 248
Voltage Rating208 to 230/460
Additional Information
AISI 304 Specified|ASTM A536 80-55-06 Specified|cURus Recognized|EN 1.4301/1563/GJS-500-7 Specified|NSF/ANSI 61 Certified
Features & Benefits
- Compact, inline design fits into small footprint Easy installation and operation with settings and internal connections done at factory Highly efficient design reduces energy consumption by up to half compared to fixed speed pumps Unique cartridge seal design can be replaced in minutes Spacer coupling allows motor to be left in place during seal replacement Remote control/fieldbus monitoring and data collection Building management system compatible User friendly controller interface with advanced features and functionality Laser welded stainless impellers promote class leading efficiency
Documents
Marketing Information
Vertical, multi-stage centrifugal pump with inlet and outlet ports on same the level (inline). The pump head and base are in cast iron - all other wetted parts are in stainless steel. A cartridge shaft seal ensures high reliability, safe handling and easy access and service. Power transmission is via a rigid split coupling. Pipe connection is via ANSI flanges. The pump is fitted with a 3 ph, fan cooled asynchronous motor.
