Rheem® Eclipse Series RGEA16060ACV102AA Gas/Electric Package Unit, 60000 Btu/hr Cooling, 100000 Btu/hr Heating Input
Rheem® Eclipse Series RGEA16060ACV102AA Gas/Electric Package Unit, 60000 Btu/hr Cooling, 100000 Btu/hr Heating Input
Rheem® Gas/Electric Package Unit, RGEA16 Prestige® Series, 060ACV102AA Model, 60000 Btu/hr Cooling, 100000 Btu/hr Heating Input BTU Rating, 208/230 VAC Voltage Rating, 28 A Amperage Rating, 17.59 kW Wattage, 1/3 hp Outdoor Fan, 1 hp Indoor Fan HP Rating, 1075 rpm Outdoor Fan, 1050 rpm Indoor Fan Rotational Speed, 60 Hz Frequency Rating, 3 ph Phase, (1) Scroll Compressor Type, 1850 cfm Rating, 10.7 EER Rating, 16 SEER Rating, 0.81 AFUE Rating, 5 ton Tonnage, 78 dBA Decibel Rating, Direct Spark Ignition Type, Variable Speed Drive Type, Outdoor Coil - 16.23 sq-ft Face Area, 22 Fins/in, Indoor Coil - 7.39 sq-ft Face Area, 15 Fins/in Coil Rating, Connection Type: 3/4 in Drain, 47-1/2 in L x 52-7/16 in W x 41 in H Dimensions
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$21,177.47 / ea
Out of Stock
- Attributes
- Additional Information
- Features & Benefits
- Documents
Attributes
BrandRheem®
AFUE Rating0.81
Amperage Rating28
CFM Rating1850
Coil RatingOutdoor Coil - 16.23 sq-' Face Area, 22 Fins/", Indoor Coil - 7.39 sq-' Face Area, 15 Fins/"
Compressor Type(1) Scroll
Connection Type3/4 " Drain
Decibel Rating78
Dimensions47-1/2 " L x 52-7/16 " W x 41 " H
Drive TypeVariable Speed
EER Rating10.7
Frequency Rating60
HP Rating1/3 hp Outdoor Fan, 1 hp Indoor Fan
Ignition TypeDirect Spark
IndustryHVAC
Input BTU Rating60000 Btu/hr Cooling, 100000 Btu/hr Heating
Model060ACV102AA
Phase3
Rotational Speed1075 rpm Outdoor Fan, 1050 rpm Indoor Fan
SEER Rating16
SeriesRGEA16 Prestige Series
Tonnage5
Voltage Rating208/230
Wattage17.59
Additional Information
AHRI Certified|ENERGY STAR Certified|cULus Listed
Features & Benefits
- All models feature scroll compressors for maximum efficiency and quiet operation, all RGEA16 models feature UltraTech™ scroll two-stage compressors with Comfort Alert™ diagnostics, high/low pressure switches and hard start kits Louvered condenser compartment for protecting the coil against yard hazards and/or weather extremes One-piece top with a deep flange to help keep water out of the unit Supply and return air openings feature a 1 in tall flange to prevent water migration into the ductwork Access panels have "weep holes" and channels to further help manage water run-off Side and down discharge options available on all models, all models are shipped ready for horizontal application Easily accessible blower section complete with slide-out blower, the variable speed motor also comes with a interface that allows for dehumidification when used in continuous humidistat, the variable speed system is capable of 1 in external static Refrigerant connections are conveniently located for easy service diagnostics Condenser and evaporator coils feature enhanced fins for better heat transfer and rifled copper tubing for greater efficiency Inside the easily accessible furnace compartment is the draft inducer motor, this is specially designed for quiet reliable operation, in addition to the draft inducer motor, the in-shot gas burners and manifold efficiently regulate the flow of gas for combustion All units feature an internal trap on the condensate line eliminating the need for installing an onsite external trap Easily accessible control box One-point wiring simplifies installation Gas/electric package units feature a tubular heat exchanger design, tubular heat exchangers are more efficient and durable than older-style clamshell heat exchangers Thermal expansion valve standard on all models for superior superheat control, reliability and energy efficiency at all operating conditions Filter drier standard on all models, rugged base rail included for improved installation and handling Complete factory charged, wired and run tested, molded compressor plugs 1st variation major Series Two-stage heat configuration Non-communicating control
Rheem® Eclipse Series RGEA16060ACV102AA Gas/Electric Package Unit, 60000 Btu/hr Cooling, 100000 Btu/hr Heating Input
BrandRheem®
MFG #RGEA16060ACV102AA
Keller #1235064
My Part ##
Last Ordered#
$21,177.47 / ea
