Samsung FJM Series AC015BNJDCH/AA Console Unit, 208 to 230 V, 0.35 A, 15000 Btu/hr Cooling, 18000 Btu/hr Heating BTU
Samsung FJM Series AC015BNJDCH/AA Console Unit, 208 to 230 V, 0.35 A, 15000 Btu/hr Cooling, 18000 Btu/hr Heating BTU
Samsung Console Unit, FJM Series, 208 to 230 V, 0.35 A, 4.4 kW Cooling, 5.28 kW Heating, 60 Hz, 1 ph, 3 Fan Speeds, 15000 Btu/hr Cooling, 18000 Btu/hr Heating, 254 to 318 cfm, Connection Type: Flared, Tonnage: 1.24 ton, 42 dBA Sound Level, Floor Mounting, HIPS, 7-13/16 in Overall Length, 28-3/8 in Overall Width, 24-7/16 in Overall Height, For Use With: AJ024BXJ3CH/AA (JXH24J3B), AJ036BXJ4CH/AA (JXH36J4B), AJ048BXJ5CH/AA (JXH48J5B), AJ020BXS3CH/AA (JXH20S3B), AJ024BXS4CH/AA (JXH24S4B), AJ030BXS4CH/AA (JXH30S4B), AJ036BXJ4CH/AA (JXH36J4B), AJ036BXS4CH/AA (JXH36S4B), AJ048BXJ5CH/AA (JXH48J5B) Outdoor Units, Additional Information: 1/2 in Gas Pipe Size, 1/4 in Liquid Pipe Size, R-410A Refrigerant Type
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$1,493.64Â /Â ea
Out of Stock
- Attributes
- Additional Information
- Features & Benefits
- Documents
- Marketing Information
Attributes
BrandSamsung
Additional Information1/2 " Gas Pipe Size, 1/4 " Liquid Pipe Size, R-410A Refrigerant Type
Amperage Rating0.35
BTU Rating15000 Btu/hr Cooling, 18000 Btu/hr Heating
CFM Rating254 to 318
Connection TypeFlared
Correct Item GroupOther Mini Split Indoor
Frequency Rating60
MaterialHIPS
Mounting TypeFloor
Number of Fan Speeds3
Overall Height24-7/16
Overall Length7-13/16
Overall Width28-3/8
Phase1
Power Rating4.4 kW Cooling, 5.28 kW Heating
SeriesFJM Series
Sound Level42
Suitable For Use WithAJ024BXJ3CH/AA (JXH24J3B), AJ036BXJ4CH/AA (JXH36J4B), AJ048BXJ5CH/AA (JXH48J5B), AJ020BXS3CH/AA (JXH20S3B), AJ024BXS4CH/AA (JXH24S4B), AJ030BXS4CH/AA (JXH30S4B), AJ036BXJ4CH/AA (JXH36J4B), AJ036BXS4CH/AA (JXH36S4B), AJ048BXJ5CH/AA (JXH48J5B) Outdoor Units
Tonnage1.24
Voltage Rating208 to 230
Additional Information
ETL Listed|UL 1995
Features & Benefits
- High-voltage terminal block temperature sensor to disable unit in the event overheating of power connection System energy consumption can be viewed using the Samsung SmartThings mobile app (not revenue grade, for reference only) Indoor fan is turbo type with a single fan motor Three fan speed settings and auto settings Washable filter as standard (included) The front panel shall have LED indicator lights, touch controls, IR receiver, and 1 motorized louver The unit shall discharge cool air from the upper outlet louver (motorized upper and lower) (manual adjustment only) outlets while in heating mode Insulated, HIPS chassis certified to UL94 V0 Control wiring shall be 2 X 16 AWG The unit shall be operated via a wireless or wired remote control with DDC type signal Dual set temperature support when connected to MWR-WG00UN Advanced Wired Controller or central control options Wired controllers must be purchased separately The unit shall ship with a wireless controller, holder, and batteres Refrigerant flow shall be controlled by an electronic expansion valve at the outdoor unit
Documents
Marketing Information
The Console unit can be installed sitting on the floor or hanging low on a wall, making it a great option for replacing a radiator in order to provide both heating and cooling in almost any space.
