Samsung AR36BSHUMGMXCV Heat Pump Split System Outdoor Unit, 208 - 230 V, 5/16.8/19.1 A Cooling, 3/20/24 A Heating, Steel
Samsung AR36BSHUMGMXCV Heat Pump Split System Outdoor Unit, 208 - 230 V, 5/16.8/19.1 A Cooling, 3/20/24 A Heating, Steel
Samsung Heat Pump Split System Outdoor Unit, 208 - 230 V, 5/16.8/19.1 A Cooling, 3/20/24 A Heating, 125 W, 60 Hz, 1 ph, 3 Fan Speeds, 40000 Btu/hr Heating, 36000 Btu/hr Cooling, 3532 cfm Condenser, 699 to 830 cfm Evaporator Heating CFM Rating, 9.5 EER Rating, 19.2 SEER, 8.5 HSPF, Flared Connection, BLDC Rotary Compressor, R-410A Refrigerant, 3/8 in Liquid Line, 5/8 in Suction Line, 35 A Fuse Rating, Inverter Drive, 52 dBA, 54 dBA Heating Sound Level, Wall Mounting, Steel, Galvanized/Powder-Coated, Gray, 4 to 75 deg F Heating Operating Temperature, 23 to 115 deg F Cooling Operating Temperature, 13 in Overall Length, 37 in Overall Width, 47-5/8 in Overall Height, Additional Information: RAC Classification, 2022 Version, Inverter R-410A HP Type, Max RAC Design
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$3,300.48Â /Â ea
Out of Stock
- Attributes
- Additional Information
- Features & Benefits
- Documents
Attributes
BrandSamsung
Additional InformationRAC Classification, 2022 Version, Inverter R-410A HP Type, Max RAC Design
Amperage Rating5/16.8/19.1 A Cooling, 3/20/24 A Heating
ColorGray
Compressor TypeBLDC Rotary
Connection TypeFlared
Cooling BTU Rating36000
Cooling Operating Temperature23 to 115
Drive TypeInverter
EER Rating9.5
FinishGalvanized/Powder-Coated
Frequency Rating60
Fuse Rating35
Heating BTU Rating40000
Heating CFM Rating3532 cfm Condenser, 699 to 830 cfm Evaporator
Heating Operating Temperature4 to 75
Heating Sound Level52 dBA, 54 dBA
HSPF Rating8.5
IndustryHVAC
Liquid Line Size3/8
MaterialSteel
Mounting TypeWall
Number of Fan Speeds3
Overall Height47-5/8
Overall Length13
Overall Width37
Phase1
Power Rating125
Refrigerant TypeR-410A
SEER Rating19.2
Suction Line Size5/8
Voltage Rating208 - 230
Warranty10 Year Compressor, 10 Year Parts, 1 Year Limited Labor
Additional Information
cETLus Listed|ETL Listed|UL 60335-2-40
Features & Benefits
- The outdoor unit shall supply power to indoor unit via 14 AWG X 3 power wire High-voltage terminal block temperature sensor to disable unit in the event of power connection overheating Auto-restart after power loss Soft-start compressor minimizing current inrush All heat exchangers shall be mechanically bonded aluminum fin to copper tube The condensing unit heat exchanger salt spray test method: ASTM-B117-18 - the heat exchanger showed no unusual rust or corrosion development to 2,280 hours Three fan speed settings and auto setting Washable filter as standard Control wiring shall be 2 X 16 AWG Wireless controller included as standard Dual set temperature support when connected to MWR-WG00UN Advanced Wired Controller or central control options
