NIBCO® 4140W Series H-41404W Ball Valve, 1 in, IPS, Brass, 210 to 600 psi
NIBCO® 4140W Series H-41404W Ball Valve, 1 in, IPS, Brass, 210 to 600 psi
NIBCO® Ball Valve, 4140W Series, 1 in Nominal, IPS Connection, Full Port, 210 to 600 psi, T-Handle Actuator, 1 in Opening, Lever Handle Operator, Brass Body, PTFE Seat, Brass Stem, PTFE Seal, Brass Packing, Steel Handle, Brass Ball, Vinyl Softgoods, Lead-Free, 100 to 366 deg F, 3-1/16 in L
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$111.50 / ea
Out of Stock
- Attributes
- Additional Information
- Features & Benefits
- Documents
Attributes
BrandWebstone
Actuator TypeT-Handle
Ball MaterialBrass
Body MaterialBrass
Connection TypeIPS
Dimensions3-1/16 " L
Handle MaterialSteel
Nominal Size1
Opening Size1
Operator TypeLever Handle
Packing MaterialBrass
Port TypeFull
Pressure Rating210 to 600
Seal MaterialPTFE
Seat MaterialPTFE
Series4140W Series
Softgoods MaterialVinyl
Stem MaterialBrass
Temperature Rating100 to 366
Additional Information
NSF/ANSI 61/372/ 14
Features & Benefits
- Easily Isolates the Pump for Replacement Prevents Electrolysis and Eliminates Galvanic Corrosion Rotating Flange is Secured by a Snug-Fit Snap-Ring that Provides Greater Control Over Positioning During Installation Flange Features a Conical Inlet to Minimize Turbulence Fits Virtually Any Standard Circulator Pump Saves 18 Minutes Replaces 3 Components Eliminates 2 Leak Paths This valve is actuated by a blowout proof stem. Adjustable Packing Gland Available in Lead-Free Available in FIP x FLG, SWT x FLG, PRS x FLG, PEX x FLG
NIBCO® 4140W Series H-41404W Ball Valve, 1 in, IPS, Brass, 210 to 600 psi
BrandWebstone
MFG #H-41404W
Keller #1267939
My Part ##
Last Ordered#
$111.50 / ea
