Samsung Ovation Series AM018RNMDCH/AA Ducted Unit, 18000 Btu/hr Cooling, 18000 Btu/hr Cooling, 20000 Btu/hr Heating BTU
Samsung Ovation Series AM018RNMDCH/AA Ducted Unit, 18000 Btu/hr Cooling, 18000 Btu/hr Cooling, 20000 Btu/hr Heating BTU
Samsung Ducted Unit, DVM S Series, 18000 Btu/hr Cooling Capacity, 20000 Btu/hr Heating Capacity, 18000 Btu/hr Cooling, 20000 Btu/hr Heating BTU Rating, 208 to 230 V Voltage Rating, 1.4 A Amperage Rating, 60 Hz Frequency Rating, 1 ph Phase, 1095 cfm, 918 cfm, 706 cfm Rating, Horizontal Configuration, R-410A Refrigerant Type, 30 dB Low, 34 dB Medium, 37 dB High Sound Level, 15 A Fuse Rating, 1-1/16 in Connection, 3/8 in Liquid Line Size, 5/8 in Suction Line Size, 3 Number of Speeds, BLDC Motor Type, 0.2 in-WC External Static, Steel, Galvanized, 11-13/16 in H x 51-3/16 in W x 27-9/16 in D Dimensions, Air Handlers & Fan Coils Correct Item Group
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$3,093.12Â /Â ea
Out of Stock
- Attributes
- Additional Information
- Features & Benefits
- Documents
Attributes
BrandSamsung
Amperage Rating1.4
BTU Rating18000 Btu/hr Cooling, 20000 Btu/hr Heating
CFM Rating1095 cfm, 918 cfm, 706 cfm
ConfigurationHorizontal
Connection Size1-1/16
Cooling Capacity18000
Correct Item GroupAir Handlers & Fan Coils
Dimensions11-13/16 " H x 51-3/16 " W x 27-9/16 " D
FinishGalvanized
Frequency Rating60
Fuse Rating15
Heating Capacity20000
IndustryHVAC
Liquid Line Size3/8
MaterialSteel
Motor TypeBLDC
Number of Speeds3
Phase1
Pressure Rating0.2 "-WC External Static
Refrigerant TypeR-410A
SeriesDVM S Series
Sound Level30 dB Low, 34 dB Medium, 37 dB High
Suction Line Size5/8
Voltage Rating208 to 230
Additional Information
cETLus Listed
Features & Benefits
- Horizontal discharge airflow The indoor unit shall have a removable EEPROM that stores system programming information, unit name, and other data All indoor unit addressing and option settings shall be done digitally; the indoor unit does not contain rotary dials or setting switches. The indoor unit shall have static pressure scanning for simple setup and optimized comfort settings for the occupant. The indoor unit shall have smart-tuning function that can provide optimized comfort by allowing the occupant to offset the fan CFM curve with a wired remote controller (MWR-SH10N, MWR-SH11UN, MWR-WE13*N, MWR-WG00J*N) to increase or decrease airflow. The indoor unit shall allow service access from four sides (top, bottom, left, right). The indoor unit shall have an internal condensate pump as standard with float switch (maximum 29" lift from bottom of unit). High-voltage terminal block temperature sensor to disable unit in the event overheating of power connection Discharge air temperature sensor with target discharge temperature control capability
Samsung Ovation Series AM018RNMDCH/AA Ducted Unit, 18000 Btu/hr Cooling, 18000 Btu/hr Cooling, 20000 Btu/hr Heating BTU
BrandSamsung
MFG #AM018RNMDCH/AA
Keller #1272475
My Part ##
Last Ordered#
$3,093.12Â /Â ea
