ApplicationFor heating, cooling, steam and vacuum applications
Ball MaterialBrass
Body MaterialBronze
ColorYellow
Configuration2-Piece
Connection TypeFNPT
Domestic/ImportDomestic
Handle MaterialSteel/Vinyl
Material StandardASTM B16, ASTM B283, ASTM B584
MediaGas, Steam, Water
Nominal Size2
Operator TypeLever Handle
Packing MaterialMPTFE
Port TypeFull
Pressure Rating150 psi WSP, 600 psi CWP
Seal MaterialPTFE
Seat MaterialRPTFE
Series77-100 Series
Softgoods MaterialMPTFE/RPTFE/PTFE
Stem MaterialBrass
Temperature Rating500
Trim MaterialBrass/RPTFE
Warranty5 Year
Shipping Dimensions (L x W x H)5.31" x 1.61" x 2.72"
Additional Information
CRN OC10908.5C cUPC|Federal Specification WW-V-35C, Type II, Composition BZ, Style 3|MSS-SP-110
Features & Benefits
Adjustable packing
Blowout-proof stem design
RPTFE seats and stuffing box ring
Hardened ball for wear-resistance
100% factory tested
Mounting pad for easy actuator mounting
Made in USA, ARRA compliant
250 lb steam trim
