ANSI B16.5|ASTM D1784/D1785/D2467|LPCB Certified|NSF Certified|UL 94 V-0 Flammability Rating

• Spears® comprehensive line of PVC injection molded fittings and extruded pipe offers a variety of configurations in sizes 1/4 in through 14 in Spears® exclusive CL150 flanges are produced in sizes 1/2 to 18 in with ANSI B16.5 bolt patterns, plus numerous unions, saddles, transition and specialty fittings in a variety of sizes Unlike metal, PVC fittings and pipe never rust, scale or pit and will provide many years of maintenance-free service and extended system life PVC thermoplastic can handle fluids at service temperatures up to 140 deg F (60 deg C), allowing a wide range of process applications, including corrosive fluids Substantially lower material costs than steel alloys or lined steel, combined with lightweight and ease of installation, can reduce installation costs by as much as 60% over conventional metal systems Smooth interior walls result in lower pressure loss and higher volume than conventional metal fittings

Spears® SCH 80 PVC product designs combine years of proven experience with computer generated stress analysis to yield the optimum physical structure and performance for each fitting. Material reinforcement is uniformly placed in stress concentration areas for substantially improved pressure handling capability. Resulting products are subjected to numerous verification tests to assure obtaining the very best PVC fittings available.
