AMES® FIRE & WATERWORKS Colt™ C200 Series 0112125 Straight Double Check Butterfly Valve, 8 in, Flanged x Grooved
AMES® FIRE & WATERWORKS Colt™ C200 Series 0112125 Straight Double Check Butterfly Valve, 8 in, Flanged x Grooved
AMES® FIRE & WATERWORKS Colt™ Straight Double Check Butterfly Valve, C200 Series, 8 in Nominal, Flanged x Grooved Connection, 175 psi, Gear Actuator, Stainless Steel Body, Rubber Seat, 140 deg F, Lead-Free, Finish: Stainless Steel, 42-3/4 in L x 14-3/16 in W x 23-5/16 in H
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$24,126.00 / ea
In Stock
- Attributes
- Additional Information
- Features & Benefits
- Documents
- Marketing Information
Attributes
BrandAMES® FIRE & WATERWORKS
Actuator TypeGear
Body MaterialStainless Steel
Connection TypeFlanged x Grooved
Dimensions42-3/4 " L x 14-3/16 " W x 23-5/16 " H
FinishStainless Steel
IndustryFire Protection
Lead-FreeYes
Nominal Size8
Pressure Rating175
Prop 65 WarningYes
Seat MaterialRubber
SeriesC200 Series
Temperature Rating140
Additional Information
ASSE 1015|AWWA C510-97|CSA B64.5|FCCCHR-USC|FM Approved|NSF Certified|UL Listed
Features & Benefits
- Light weight lead free stainless steel body for long term corrosion protection Short lay length for retrofits Grooved gear butterfly valves Patented torsion spring design
Marketing Information
This 8 IN lead free stainless steel double check valve backflow preventer assembly is equipped with a post indicator valve and grooved gear butterfly valves. Ideally suited for referenced cross-connections identified as non-health hazard continuous pressure applications, it prevents the backflow of contaminated water into the potable water supply and protects against backsiphonage and backpressure. The easy maintenance assembly consists of positive seated thermoplastic independently operating torsion spring check modules, resilient seated butterfly valves and top mounted test cocks. The temperature range is 33 to 140 degrees F (0.5 to 60 degrees C). The maximum working pressure is 175 psi (12.1 bar).
AMES® FIRE & WATERWORKS Colt™ C200 Series 0112125 Straight Double Check Butterfly Valve, 8 in, Flanged x Grooved
BrandAMES® FIRE & WATERWORKS
MFG #0112125
Keller #1308238
My Part ##
Last Ordered#
$24,126.00 / ea
