Samsung WindFree™ AR09CSDABWKXCV Outdoor Evaporator Split System, 208 to 230 V, 1/2.8/5.2/1/3.4/9 A, 1 ph, Steel
Samsung WindFree™ AR09CSDABWKXCV Outdoor Evaporator Split System, 208 to 230 V, 1/2.8/5.2/1/3.4/9 A, 1 ph, Steel
Samsung WindFree™ Outdoor Evaporator Split System, 208 to 230 V, 1/2.8/5.2/1/3.4/9 A, 40 W, 60 Hz, 1 ph, 3 Fan Speeds, 2400 to 21000 Btu/hr Heating, 3000 to 13000 Btu/hr Cooling, 427 cfm Heating CFM Rating, 392 cfm Cooling CFM Rating, 15.5 EER Rating, 24.5 SEER, 10.5 HSPF, BLDC Rotary Compressor, R-410A Refrigerant, 3/8 in Liquid Line, 1/4 in Suction Line, 20 A Fuse Rating, 45 dB Heating Sound Level, 38 dB Cooling Sound Level, Wall Mounting, Steel, Baked-On Powder-Coated/Galvanized, -5 to 75 deg F Heating Operating Temperature, 14 to 115 deg F Cooling Operating Temperature, 31-1/8 in Overall Width, 21-9/16 in Overall Height, Additional Information: 11-1/4 in D
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$1,589.76 / ea
In Stock
- Attributes
- Additional Information
- Features & Benefits
- Documents
Attributes
BrandSamsung
Additional Information11-1/4 " D
Amperage Rating1/2.8/5.2/1/3.4/9
Compressor TypeBLDC Rotary
Cooling BTU Rating3000 to 13000
Cooling CFM Rating392
Cooling Operating Temperature14 to 115
Cooling Sound Level38
EER Rating15.5
FinishBaked-On Powder-Coated/Galvanized
Frequency Rating60
Fuse Rating20
Heating BTU Rating2400 to 21000
Heating CFM Rating427
Heating Operating Temperature-5 to 75
Heating Sound Level45
HSPF Rating10.5
IndustryHVAC
Liquid Line Size3/8
MaterialSteel
Mounting TypeWall
Number of Fan Speeds3
Overall Height21-9/16
Overall Width31-1/8
Phase1
Power Rating40
Refrigerant TypeR-410A
SEER Rating24.5
Suction Line Size1/4
Voltage Rating208 to 230
Additional Information
AHRI 210/240|cETLus Listed|ENERGY STAR Certified|UL 60335-2-40
Features & Benefits
- In cooling mode, as room temperature nears set temperature, the unit will close its louver and will disperse air into the space through thousands of micro holes on the front of the indoor unit preventing cold air drafts on occupants Outdoor unit shall provide 208/230 V power to indoor unit via three 14 AWG interconnect power cable Built-in motion sensor for airflow direction control and energy saving operation The outdoor unit shall be galvanized steel with a baked on powder-coated finish for durability The heat exchangers shall be mechanically bonded fin to copper tube The compressor shall be hermetically sealed, inverter controlled, BLDC rotary Refrigerant flow shall be controlled by an electronic expansion valve at the outdoor unit Three-fan speed settings and auto setting Automatic (motorized) vertical swing (up/down) and horizontal swing (left/right) louvers The system shall have a built-in Wi-Fi adapter as standard to allow control and monitoring using the Samsung SmartThings app (Android, iOS) Dual set temperature support when connected to MWR-WG00UN advanced wired controller Samsung central control compatible (MIM-R10UN accessory required) Interconnect control wire between outdoor and indoor unit shall be two 16 AWG
Documents
Samsung WindFree™ AR09CSDABWKXCV Outdoor Evaporator Split System, 208 to 230 V, 1/2.8/5.2/1/3.4/9 A, 1 ph, Steel
BrandSamsung
MFG #AR09CSDABWKXCV
Keller #1310804
My Part ##
Last Ordered#
$1,589.76 / ea
