Samsung WindFree™ 3.0 AR12CSDABWKXCV RXS12ABC Heat Pump Split System Outdoor Unit, 208 - 230 V, 12000 Btu/hr Heating
Samsung WindFree™ 3.0 AR12CSDABWKXCV RXS12ABC Heat Pump Split System Outdoor Unit, 208 - 230 V, 12000 Btu/hr Heating
Samsung WindFree™ 3.0 Heat Pump Split System Outdoor Unit, Model: AR12CSDABWKXCV, 208 - 230 V, 1/4.2/6.3 A Cooling, 1.1/3.8/9 A Heating, 40 W Condenser, 27 W Evaporator, 60 Hz, 1 ph, 3 Fan Speeds, 12000 Btu/hr Heating, 1589 cfm Condenser Heating CFM Rating, 13.5 EER Rating, 23 SEER, 10.5 HSPF, Flared Connection, BLDC Rotary Compressor, R-410A Refrigerant, 20 A Fuse Rating, Inverter Drive, 47 dBA, 28 dBA Heating Sound Level, Wall Mounting, Steel, Galvanized/Powder-Coated, 5 to 75 deg F Heating Operating Temperature, 14 to 115 deg F Cooling Operating Temperature, 11-1/4 in Overall Length, 31-1/8 in Overall Width, 21-9/16 in Overall Height, Additional Information: RAC Classification, 2023 Version, Inverter R-410A HP Type, WindFree Geo Design, Motion Detect Sensor, Wi-Fi Feature
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$1,852.20 / ea
Out of Stock
- Attributes
- Additional Information
- Features & Benefits
- Documents
- Marketing Information
Attributes
BrandSamsung
Additional InformationRAC Classification, 2023 Version, Inverter R-410A HP Type, WindFree Geo Design, Motion Detect Sensor, Wi-Fi Feature
Amperage Rating1/4.2/6.3 A Cooling, 1.1/3.8/9 A Heating
Compressor TypeBLDC Rotary
Connection TypeFlared
Cooling Operating Temperature14 to 115
Drive TypeInverter
EER Rating13.5
FinishGalvanized/Powder-Coated
Frequency Rating60
Fuse Rating20
Heating BTU Rating12000
Heating CFM Rating1589 cfm Condenser
Heating Operating Temperature5 to 75
Heating Sound Level47 dBA, 28 dBA
HSPF Rating10.5
MaterialSteel
ModelAR12CSDABWKXCV
Mounting TypeWall
Number of Fan Speeds3
Overall Height21-9/16
Overall Length11-1/4
Overall Width31-1/8
Phase1
Power Rating40 W Condenser, 27 W Evaporator
Refrigerant TypeR-410A
SEER Rating23
Voltage Rating208 - 230
Shipping Dimensions (L x W x H)14.75" x 37.38" x 11.44"
Additional Information
AHRI Certified|cETLus Listed|ENERGY STAR® Certified|UL 60335-2-40
Features & Benefits
- The indoor unit shall feature WindFree™* mode. In cooling mode, as room temperature nears set temperature, the unit will close its louver and will disperse air into the space through thousands of micro-holes on the front of the indoor unit preventing cold air drafts on occupants The indoor unit shall have Wi-Fi capability as standard Outdoor unit shall provide 208/230V power to indoor unit via 14 AWG X 3 interconnect power cable Indoor unit chassis shall be UL94 V0 with a galvanized steel mounting bracket The indoor unit shall have easy-access to wire, pipe, and drain connections via access panel on the bottom of the unit for simple installation and service The outdoor unit shall be galvanized steel with a baked on powder coated finish for durability The heat exchangers shall be mechanically bonded fin to copper tube The compressor shall be hermetically sealed, inverter controlled, BLDC Rotary Refrigerant flow shall be controlled by an electronic expansion valve at the outdoor unit The indoor fan shall be a single, antibacterial cross-flow type Three fan speed settings and auto setting Automatic (motorized) vertical swing (up/down) and horizontal swing (left/right) louvers The system shall have a built in Wi-Fi adapter as standard to allow control and monitoring using the Samsung SmartThings app (Android, iOS) Dual set temperature support when connected to MWR-WG00UN Advanced Wired Controller and supported central control options
Marketing Information
Samsung's exclusive Wind-Free™* cooling technology provides users with a cool indoor climate without the discomfort of direct cold airflow. It's an advantage no other system can match.
