Grundfos CR Series 96083192 13-Stage Centrifugal Pump, 3 hp, 25 mm, 32 mm Inlet Connection, 15.4 gpm
Grundfos CR Series 96083192 13-Stage Centrifugal Pump, 3 hp, 25 mm, 32 mm Inlet Connection, 15.4 gpm
Grundfos 13-Stage Centrifugal Pump, Series: CR Series, 60 Hz Frequency, HP Rating: 3 hp, 25 mm, 32 mm Inlet Connection, 25 mm, 32 mm Outlet Connection, 15.4 gpm Flow Rate, 362.59 psi Maximum, 410.1 ft Maximum Head, 3461 rpm Speed, -4 to 248 deg F, 182TC Frame, Vertical Mounting, Cast Iron/Stainless Steel Housing, 9.84 in Overall Length, 8.27 in Overall Width, 20.2 in Overall Height
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$2,943.00Â /Â ea
Out of Stock
- Attributes
- Additional Information
- Features & Benefits
- Documents
- Marketing Information
Attributes
BrandGrundfos
Flow Rate15.4
Frame182TC
Frequency Rating60
Housing MaterialCast Iron/Stainless Steel
HP Rating3
IndustryPlumbing
Inlet Connection Size25 mm, 32 mm
Maximum Head410.1
Maximum Pressure362.59
Mounting TypeVertical
Outlet Connection Size25 mm, 32 mm
Overall Height20.2"
Overall Length9.84
Overall Width8.27
SeriesCR Series
Speed Rating3461
Temperature Rating-4 to 248
Additional Information
AISI 304 Specified|ASTM A48-25B Specified|CE Marked|EN 1.4301/1561/GJL-200 Specified|NSF/ANSI 61 Certified
Features & Benefits
- Compact, inline design fits into small footprint Easy installation and operation with settings and internal connections done at factory Highly efficient design reduces energy consumption by up to half compared to fixed speed pumps Unique cartridge seal design can be replaced in minutes Spacer coupling allows motor to be left in place during seal replacement Remote control/fieldbus monitoring and data collection Building management system compatible User friendly controller interface with advanced features and functionality Laser welded stainless impellers promote class leading efficiency 13 flow sizes, capable of producing up to almost 725 psi pressure and with a variety of shaft seals, rubber materials and supply voltages
Documents
Marketing Information
Vertical, multi-stage centrifugal pump with inlet and outlet ports on same the level (inline). The pump head and base are in cast iron - all other wetted parts are in stainless steel. A cartridge shaft seal ensures high reliability, safe handling and easy access and service. Power transmission is via a rigid split coupling. Pipe connection is via combined DIN-ANSI-JIS flanges.
Grundfos CR Series 96083192 13-Stage Centrifugal Pump, 3 hp, 25 mm, 32 mm Inlet Connection, 15.4 gpm
BrandGrundfos
MFG #96083192
Keller #1339186
My Part ##
Last Ordered#
$2,943.00Â /Â ea
