DELTA® 81T231-30 Urinal Flush Valve, 1 in, 3/4 in Nominal, FIP x Copper Sweat, 25 psi
DELTA® 81T231-30 Urinal Flush Valve, 1 in, 3/4 in Nominal, FIP x Copper Sweat, 25 psi
DELTA® Urinal Flush Valve, Series: 81T2 Series, FIP x Copper Sweat Connection Type, 1 in, 3/4 in Nominal, 25 psi, 8 gpm, Media: Water, Oscillating Actuator, 13 in Inlet to Outlet Length, 4-3/4 in Top to Inlet Center, 1 Handles, 0.5 gpf Flush, Manual Operator, Polished Chrome-Plated
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$198.00 / ea
Out of Stock
- Attributes
- Additional Information
- Features & Benefits
- Documents
- Marketing Information
Attributes
BrandDELTA®
Actuator TypeOscillating
Collectiont
Connection TypeFIP x Copper Sweat
FinishPolished Chrome-Plated
Flow Rate8
Flush Rate0.5
FunctionFlush Valve
Functional SeriesExcluded
HandleSingle Handle other or Single Hole Sink
Inlet to Outlet Length13
MediaWater
ModelDcm-81t231-30
Nominal Size1 ", 3/4 "
Number of Handles1
Number of Tiers1
Operator TypeManual
Pressure Rating25
Product Weight7.15
Series81T2 Series
Sub-FunctionExposed
Top to Inlet Center4-3/4
Additional Information
ADA Compliant|ASME A112.1037/CSA B125.37|ASSE 1037|ICC/ANSI A117.1
Features & Benefits
- Manual flush valve for 3/4" top spud flushing urinal with sensor on valve - maximum 13" height Polished chrome-plated Modified tail to fit SLOAN/ZURN stops EZ Adjust system allows flush volume adjustments with a simple turn of a screw Right or left-hand supply installation ADA compliant lever handle Teck chloramine resistant diaphragm for smooth operation Vacuum breaker 1" FIP/ 3/4" Copper sweat inlet Field adjustable from 0.125-1.0 gpf (0.47-3.78 lpf) and factory set to 0.5 gpf (1.9 lpf)
Documents
Marketing Information
Exposed manual flush valve for 0.75" (19 mm) top spud urinal fixture, less angle stop, with quiet action chloramine-resistant diaphragm and adjustable flush volume factory set to 0.5 gpf (1.9 Lpf). Fits Sloan® / Zurn® models.
DELTA® 81T231-30 Urinal Flush Valve, 1 in, 3/4 in Nominal, FIP x Copper Sweat, 25 psi
BrandDELTA®
MFG #81T231-30
Keller #1387957
My Part ##
Last Ordered#
$198.00 / ea
