M-VCO UPBA-100SP2XH-1-1/4 LF BL VALVE
M-VCO UPBA-100SP2XH-1-1/4 LF BL VALVE
Milwaukee Valve Ultrapress™ Ultra Pure™ Ball Valve, Lead Free 2-Piece, Series: UPBA100S P2, 1-1/4 in Nominal, Press, 200 psi WOG, 250 deg F, Standard Port, 1.31 in Orifice, 316 Stainless Steel Ball, 7.57 in Inlet to Outlet Length, 2.82 in Top to Inlet Center, Cast Bronze Body, 316 Stainless Steel Stem and RPTFE Seat Trim, RPTFE/PTFE Softgoods, Domestic
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$807.59 / ea
Out of Stock
- Attributes
- Additional Information
- Features & Benefits
- Documents
Attributes
BrandMilwaukee Valve
Ball Material316 Stainless Steel
Body MaterialCast Bronze
Domestic/ImportDomestic
End StylePress
Inlet to Outlet Length7.57"
Nominal Size1-1/4"
Orifice Size1.31"
Port TypeStandard
Pressure Rating200 psi WOG
SeriesUPBA100S P2
Softgoods MaterialRPTFE/PTFE
Temperature Rating250
Top to Inlet Center2.82"
Trim Material316 Stainless Steel Stem and RPTFE Seat
Type2-Piece
Additional Information
ASTM B584 C89833 Body|ASTM A276 S31600 Ball/Stem|MSS SP 110|NSF/ANSI 372|PROP65: Cancer and Reproductive Harm. California Transparency in Supply Chains Act of 2010.
Features & Benefits
- XH: Extension stem Blow-out proof stem Zinc plated steel Handle 25% glass filled RPTFE thrust washer 15% glass filled RPTFE seat Revision: A RPTFE seal/thrust washer and PTFE packing
M-VCO UPBA-100SP2XH-1-1/4 LF BL VALVE
BrandMilwaukee Valve
MFG #UP15555
Keller #1423098
My Part ##
Last Ordered#
$807.59 / ea
