RUUD® Endeavor® Line RHPXYB048AJT000NA Packaged Heat Pump Unit, 45500 Btu/hr Heating, 48000 Btu/hr Cooling, 4.29 kW
RUUD® Endeavor® Line RHPXYB048AJT000NA Packaged Heat Pump Unit, 45500 Btu/hr Heating, 48000 Btu/hr Cooling, 4.29 kW
RUUD® Packaged Heat Pump Unit, Achiever® Series, RHPXYB Model, 48000 Btu/hr Cooling BTU Rating, 45500 Btu/hr Heating BTU Rating, 208/230 V Voltage Rating, 35 A Amperage Rating, 4.29 kW Wattage, 1/3 hp Rating, 60 Hz Frequency Rating, 1 ph Phase, 1050 rpm Rotational Speed, 1-Stage Scroll Compressor Type, 1600 cfm Rating, 13.4 SEER Rating, 6.7 HSPF Rating, 10.6 EER Rating, R-454B Refrigerant Type, 1 Number of Stages, 45 to 50 A Fuse Rating, 80 dBA Sound Level, Direct Drive Type, 16.29 sq-ft Face Area Coil Rating, 16 FPI Fins per Inch, 30 x 16 x 1 in Filter Size, 41 in H x 47-1/2 in W x 50-11/16 in D Dimensions, Non-Communicating, No Electric Heat Additional Information
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$19,058.59 / ea
In Stock
- Attributes
- Additional Information
- Features & Benefits
- Documents
Attributes
BrandRheem®
Additional InformationNon-Communicating, No Electric Heat
Amperage Rating35
CFM Rating1600
Coil Rating16.29 sq-' Face Area
Compressor Type1-Stage Scroll
Cooling BTU Rating48000
Dimensions41 " H x 47-1/2 " W x 50-11/16 " D
Drive TypeDirect
EER Rating10.6
Filter Size30 x 16 x 1
Fins per Inch16
Frequency Rating60
Fuse Rating45 to 50
Heating BTU Rating45500
HP Rating1/3
HSPF Rating6.7
ModelRHPXYB
Number of Stages1
Phase1
Refrigerant TypeR-454B
Rotational Speed1050
SEER Rating13.4
SeriesACHIEVER Series
Sound Level80
Voltage Rating208/230
Wattage4.29
Additional Information
AHRI Standard 210/240/270/360|cULus Listed
Features & Benefits
- Scroll Compressors on all Models: Provides maximum efficiency and quiet operation MicroChannel Evaporator and Condenser Coil: Delivers superior performance with a robust surface, a decreased refrigerant requirement and is lighter than conventional copper tube/aluminum fin coils. All-aluminum construction offers superior protection against formicary corrosion and aluminum tube rubbing damage. The design allows for easier and faster cleaning Two Thermal Expansion Valves: Standard on all models for precise superheat control, reliability, and energy efficiency at all operating conditions High and Low Pressure Control: Standard on all models for refrigerant component protection and reliability Filter drier: Standard on all models 100% factory run tested PlusOne® Refrigerant Detection System™: An integrated one-box, patented design featuring the A2L sensor and mitigation board, offering easier commissioning with a single component and simplified wiring configuration, compatibility with any 24V thermostat application and system protection by automatically pausing outdoor unit operation — if excess refrigerant is detected Rugged Base Rail: Contributes to improved installation and handling Easily Accessible Control Box and Slide-Out Blower Section: Allows for faster installability and serviceability Side and Down Discharge Options Available: All models are shipped ready for horizontal applications but can be adjusted depending on installation requirements Double Sloped Evaporator Coil Drain Pan: Allows for complete water removal from the unit—contributing to improved indoor air quality Louvered Condenser Compartment: Protects the coil against yard hazards and/or weather extremes Supply and Return Air Openings: Feature a one-inch-tall flange to prevent water migration into the ductwork Supplemental Electric Heating Option Available: Factory and field installed, electrical heat strips, up to 15 kW with simplified single-point wiring, are available for periods of extreme weather conditions Designing for Sustainability with Low GWP: For 2025, the Environmental Protection Agency (EPA) has set a global warming potential (GWP) limit of 700 for refrigerant used in heating and cooling systems. This new requirement will result in a 78%1 lower GWP than previous-generation refrigerants with only minimal changes to system installation. For us, this is another step toward our continued sustainability goal of reducing greenhouse gas emissions, while still delivering an exceptional level of energy efficient, dependable comfort
RUUD® Endeavor® Line RHPXYB048AJT000NA Packaged Heat Pump Unit, 45500 Btu/hr Heating, 48000 Btu/hr Cooling, 4.29 kW
BrandRheem®
MFG #RHPXYB048AJT000NA
Keller #1433095
My Part ##
Last Ordered#
$19,058.59 / ea
