ANSI-ASME B40.1 Grade B

• Tube and socket, bronze, soft soldered to socket and tip, brass socket Case and Window, drawn steel case, finished in black with push in polycarbonate window Dial white-coated metal lithographed with black and red graduations lines and numerals, dual scale psi and kPa Movement all brass construction, precision gear and pinion, mounted on socket independent of case Pointer - balanced design, aluminum in black finish 2% accuracy of the middle third of the entire range

WEISS instruments TL gauges are intended for general service conditions, for pressure or vacuum on air, oil, water, gas or other mediums that do not attack brass. TL gauges are furnished in drawn steel cases, finished in black. The 1-1/2 in dials are supplied with 1/8 in NPT and 2 in dial versions are available with 1/4 in or 1/8 in NPT connections. All other dial sizes are 1/4 in NPT. All gauges conform with ANSI B40.1 accuracy-grade B-2 mid scale.
