Rheem® Endeavor™ C5 Series C5QA-X37U-B RGEAZR060AJT101NAAJA Standard iR Gas/Electric Package Unit, 5 ton, 208/230 V

Rheem® Endeavor™ C5 Series C5QA-X37U-B RGEAZR060AJT101NAAJA Standard iR Gas/Electric Package Unit, 5 ton, 208/230 V

Rheem® Endeavor™ C5 Series C5QA-X37U-B RGEAZR060AJT101NAAJA Standard iR Gas/Electric Package Unit, 5 ton, 208/230 V

MFG #RGEAZR060AJT101NAAJA

Item #1437583

Mfr. Part #RGEAZR060AJT101NAAJA

UPC #66202163848

Rheem® Standard iR Gas/Electric Package Unit, RGEAZR Classic® Series, 060AJT101/X Model, 60000 Btu/hr Cooling, 100000 Btu Heating Input BTU Rating, 81000 Btu Heating Output BTU Rating, 208/230 V Voltage Rating, 41 A Minimum Circuit, 2.3 A Full Load Condenser Motor, 8.9 A Full Load Evaporator Fan Amperage Rating, 5.16 kW Wattage, 1 hp Indoor Fan, 1/2 hp Outdoor Fan HP Rating, 1050 rpm Rotational Speed, 60 Hz Frequency Rating, 1 ph Phase, Scroll Compressor Type, 2000/1700 cfm Rating, 10.6 EER Rating, 13.4 SEER Rating, 81 % AFUE Rating, 5 ton Tonnage, 5 Number of Burners, 1 Heat Number of Stages, R-410A Refrigerant Type, 77 dB Decibel Rating, Roof Curb Mounting Type, Ducted Vent, Ducted or Ductless, Direct Spark Ignition Type, Constant Torque Drive Type, 12 in D x 9 in W in Blower Size, 3.96 sq-ft Face Area Indoor, 15.37 sq-ft Face Area Outdoor Coil Rating, 1/2 in Gas Connection, 3/4 in NPT Drain Connection, (1) 1 x 24 x 24 in Filter Size, 82 % Steady State Efficiency, Aluminum Fin/Copper Tube/Stainless Steel Heat Exchanger, 45 to 75 deg F Rise Temperature Rating, 41 in H x 47-1/2 in W x 52-7/16 in D Dimensions, ResiPack Convertible Platform, Base Tier, 1st Design Major and Minor Series, Non-Communicating Control Additional Information

Why Create an Account?

  • Ability to track orders
  • More Options & Savings
  • Amazing Customer Service
$17,688.17 / ea
Out of Stock
Attributes
BrandRheem®
Additional InformationResiPack Convertible Platform, Base Tier, 1st Design Major and Minor Series, Non-Communicating Control
AFUE Rating81
Amperage Rating41 A Minimum Circuit, 2.3 A Full Load Condenser Motor, 8.9 A Full Load Evaporator Fan
Blower Size12 " D x 9 " W
CFM Rating2000/1700
Coil Rating3.96 sq-' Face Area Indoor, 15.37 sq-' Face Area Outdoor
Compressor TypeScroll
Connection Size1/2 " Gas
Decibel Rating77
Dimensions41 " H x 47-1/2 " W x 52-7/16 " D
Drain Connection3/4 " NPT
Drive TypeConstant Torque
EER Rating10.6
Filter Size(1) 1 x 24 x 24
Frequency Rating60
HP Rating1 hp Indoor Fan, 1/2 hp Outdoor Fan
Ignition TypeDirect Spark
IndustryHVAC
Input BTU Rating60000 Btu/hr Cooling, 100000 Btu Heating
MaterialAluminum Fin/Copper Tube/Stainless Steel Heat Exchanger
Model060AJT101/X
Mounting TypeRoof Curb
Number of Burners5
Number of Stages1 Heat
Output BTU Rating81000 Btu Heating
Phase1
Refrigerant TypeR-410A
Rotational Speed1050
SEER Rating13.4
SeriesRGEAZR Classic Series
Steady State Efficiency82
Temperature Rating45 to 75 deg F Rise
Tonnage5
Voltage Rating208/230
Wattage5.16
