NIBCO®
NIBCO 600RS-CB-3/4 NOM STP CPLG
NIBCO®
NIBCO 600RS-CB-3/4 NOM STP CPLG
MFG #9001253CB
Item #1466734
Mfr. Part #9001253CB
UPC #039923300751
NIBCO® Coupling, Series: 600RS-CB Series, Coupling Fitting, 3/4 in Connection Size 1, C Connection Type 1, 3/4 in Connection Size 2, C Connection Type 2, C|C Connection Type, Copper, Wrot Copper Material Construction, 0.95 in Tube OD, Dimension Standards: MSS SP-104, 1.59 in L, 700 psi, -20 to 400 deg F, Additional Information: ASTM B75 Material Standard
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$7.30 / ea
Out of Stock
- Attributes
- Additional Information
- Features & Benefits
- Documents
- Marketing Information
Attributes
BrandNIBCO®
Additional InformationASTM B75 Material Standard
Connection Size 13/4
Connection Size 23/4
Connection TypeC|C
Connection Type 1C
Connection Type 2C
Dimension StandardsMSS SP-104
Dimensions1.59 " L
Fitting TypeCoupling
IndustryPlumbing
MaterialCopper
Material ConstructionWrot Copper
Pressure Rating700
Series600RS-CB Series
Temperature Rating-20 to 400
Tube OD0.95
Additional Information
ASME/ANSI B16.22|NSF/ANSI/CAN 61/372|UL 207
Features & Benefits
- Lead-free
- Dezincification resistant
- ASTM B75 Alloy C12200
- NSF/ANSI/CAN-61 and 372
- Material and workmanship per ASME B16.22
- Material, workmanship and dimensions per MSS SP-104
- NFPA 99 Health Care Facilities Gas and Vacuum Systems and the Compressed Gas Association, Pamphlet G4.1 (medical gas)
- UL 207 Recognized to 700 PSI (select diameters)
Documents
Marketing Information
The coupling features solder cups and a rolled stop. The fitting provides a means of connecting two lengths of tube together. In addition to its inherent qualities of beauty, durability and low maintenance, copper's reusability makes it an ideal application in sustainable projects. NIBCO® copper fittings are manufactured in an ISO 9001 certified facility and backed by a 50 year limited warranty. Because of its longstanding reputation for innovation and precision in design and manufacturing, NIBCO® is the preferred brand in the industry.
