Grundfos CRN Series CRN 15-2 99917598 2-Stage Centrifugal Pump, 5 hp, 1 ph, 208 to 230 V, 50 mm Inlet Connection
Grundfos CRN Series CRN 15-2 99917598 2-Stage Centrifugal Pump, 5 hp, 1 ph, 208 to 230 V, 50 mm Inlet Connection
Grundfos 2-Stage Centrifugal Pump, Series: CRN, Model: CRN 15-2, 208 to 230 V, Amperage Rating: 31.7 to 25.3 A, 60 Hz Frequency, HP Rating: 5 hp, Phase: 1 ph, 50 mm Inlet Connection, Outlet Connection Size: 50 mm, 90.3 gpm Flow Rate, Maximum Pressure: 362.59 psi, Maximum Head: 135-1/2 ft, 3468 rpm Speed, Motor Type: WEG - Squirrel Cage Induction, Motor Speed Rating: 3515 rpm, Service Factor: 1.15, -4 to 248 deg F, Frame: 182TC, EPDM/Silicon Carbide/Stainless Steel Housing, 11.8 in Overall Length, 9.76 in Overall Width
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
Call for Price / ea
Out of Stock
- Attributes
- Additional Information
- Documents
- Marketing Information
Attributes
BrandGrundfos
Amperage Rating31.7 to 25.3
Flow Rate90.3
Frame182TC
Frequency Rating60
Housing MaterialEPDM/Silicon Carbide/Stainless Steel
HP Rating5
Inlet Connection Size50
Maximum Head135-1/2
Maximum Pressure362.59
ModelCRN 15-2
Motor Speed Rating3515
Motor TypeWEG - Squirrel Cage Induction
Outlet Connection Size50
Overall Length11.8
Overall Width9.76
Phase1
SeriesCRN
Service Factor1.15
Speed Rating3468
Temperature Rating-4 to 248
Voltage Rating208 to 230
Additional Information
AISI 316 Specified | EN 1.4401/1.4408 Specified | NSF/ANSI 61 Certified | UL Recognized
Marketing Information
Vertical, multi-stage centrifugal pump with inlet and outlet ports on same the level (inline). Pump materials in contact with the liquid are in high-grade stainless steel. A cartridge shaft seal ensures high reliability, safe handling and easy access and service. Power transmission is via a rigid split coupling. Pipe connection is via combined DIN-ANSI-JIS flanges. The pump is fitted with a 1 ph, fan cooled asynchronous motor.
Grundfos CRN Series CRN 15-2 99917598 2-Stage Centrifugal Pump, 5 hp, 1 ph, 208 to 230 V, 50 mm Inlet Connection
BrandGrundfos
MFG #99917598
Keller #1485894
My Part ##
Last Ordered#
Call for Price / ea
