Rheem® Renaissance™ RGED Line Classic® Series RGEDYB102ACG15BAAAA0 Packaged Gas Electric Unit, 99000 Btu/hr Input, 46 A
Rheem® Renaissance™ RGED Line Classic® Series RGEDYB102ACG15BAAAA0 Packaged Gas Electric Unit, 99000 Btu/hr Input, 46 A
Rheem® Packaged Gas Electric Unit, RGED Line Classic® Series, Model: 102ACG, Input BTU Rating: 99000 Btu/hr, Output BTU Rating: 150000 Btu/hr, 208-230 V, 46 A, 29 kW Wattage, 1/5 hp, 1725 rpm Rotational Speed, 60 Hz, 3 ph, Scroll Compressor, 2-Stage, 3300 cfm, 3400 cfm, 14.6 IEER, 11 EER Rating, 81 % AFUE Rating, Tonnage: 8.5 ton, 6 Burners, 2 Stages, R-454B Refrigerant, 81 dB Decibel, Rooftop Mounting, Vent, Ducted or Ductless: Ducted, Direct Spark Ignition, Direct Drive, Blower Size: 15 x 15 in, 1-Row, 20 FPI, 10.1 sq-ft Face Area Coil, 3/4 in Connection, 3/4 in Drain Connection, 2 x 20 x 20 in Filter, 60 A Fuse Rating, 81 % Steady State Efficiency, Sheet Metal, Enamel, 120 deg F, 59-1/2 in L 90-1/8 in W x 50 in H, Additional Information: CoreCommand™ Control, Medium Commercial Cabinet Type, Standard Efficiency
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$42,888.41 / ea
In Stock
- Attributes
- Additional Information
- Features & Benefits
- Documents
- Marketing Information
Attributes
BrandRheem®
Additional InformationCoreCommand Control, Medium Commercial Cabinet Type, Standard Efficiency
AFUE Rating81
Amperage Rating46
Blower Size15 x 15
CFM Rating3300 cfm, 3400 cfm
Coil Rating1-Row, 20 FPI, 10.1 sq-' Face Area
Compressor TypeScroll
Configuration2-Stage
Connection Size3/4
Decibel Rating81
Dimensions59-1/2 " L 90-1/8 " W x 50 " H
Drain Connection3/4
Drive TypeDirect
EER Rating11
Filter Size2 x 20 x 20
FinishEnamel
Frequency Rating60
Fuse Rating60
HP Rating1/5
IEER Rating14.6
Ignition TypeDirect Spark
Input BTU Rating99000
MaterialSheet Metal
Model102ACG
Mounting TypeRooftop
Number of Burners6
Number of Stages2
Output BTU Rating150000
Phase3
Refrigerant TypeR-454B
Rotational Speed1725
SeriesRGED Line Classic Series
Steady State Efficiency81
Temperature Rating120
Tonnage8.5
Voltage Rating208-230
Wattage29
Additional Information
AHRI Certified|ASHRAE 90.1|cULus Listed
Features & Benefits
- Optional hot gas reheat (HumidiDry®) available on all models for tighter humidity control and better comfort Patented flex-fit filter rack and qwik-clean drain pain for quick, easy service and maintenance PlusOne® Diagnostics come standard through CoreCommand™ with easy-to-read and understand fault codes, history, and input/output options to meet building compliance needs Optional ClearControl™ includes factory-installed Direct Digital Control (DDC) and sensors for easy connectivity through Modbus®, LonWorks®, or BACnet®
Marketing Information
Renaissance products are designed with a flexible footprint, thoughtfully engineered for easy, direct replacement of most other manufacturer's products without a roofcurb adapter. These units also boast industry-leading serviceability features, including the slide out, qwik-clean drain pan, the qwik-slide blower assembly, tool-less access to the patented flex-fit filter rack, and easy-access external gauge ports. Units meet or exceed ASHRAE 90.1 energy efficiency levels and are rigorously SEET tested to perform reliably in extreme environments, delivering powerful cooling operation up to 125 deg F.
