RIDGID® 49298 Transportable Pipe Beveller, 4 in and Larger Pipe, 120 V, 1.2 hp, 950 rpm Speed, 15.8 in OAL
RIDGID® 49298 Transportable Pipe Beveller, 4 in and Larger Pipe, 120 V, 1.2 hp, 950 rpm Speed, 15.8 in OAL
RIDGID® Transportable Pipe Beveller, 4 in and Larger Pipe Capacity, Wall/Plate Thickness: 0.188 to 0.5 in, 120 V, 13 A, 50/60 Hz, 1.2 hp, 1 ph, 950 rpm, Steel Housing, 15.8 in Overall Length, 11-1/2 in Overall Width, Additional Information: 13.3 in H Dimensions, 0 to 3/16 in W Land
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$5,886.45 / ea
Out of Stock
- Attributes
- Features & Benefits
- Documents
- Marketing Information
Attributes
BrandRIDGID®
Additional Information13.3 " H Dimensions, 0 to 3/16 " W Land
Amperage Rating13
Frequency Rating50/60
Housing MaterialSteel
HP Rating1.2
IndustryPlumbing
Overall Length15.8
Overall Width11-1/2
Phase1
Pipe Capacity4 " and Larger
Speed Rating950
Voltage Rating120
Wall/Plate Thickness0.188 to 0.5"
Features & Benefits
- Six built-in cutter inserts work simultaneously to create an accurate and machined finish. Spark-free operation also leaves pipe cool-to-the-touch immediately following a bevel. Patent-pending clamp system firmly secures the tool to the pipe. Speed monitoring with LED indicators enhance cutter performance. Adjustable land width up to 3/16-inches to fit a welder's requirements. Fast to set-up and operate. Speed monitoring with led indicators for optimal cutter performance. Capacity: 4'' pipe and larger, flat plate Pipe Wall/ Plate Thickness: Min 0.188 in (4.8 mm)/Max 0.50 in (12.7 mm) Models Equipped with -: 37.5deg;30deg or 45deg (with Optional Cutter Heads) Cutter Head: Rated for most steel & stainless steel* Size: 15.8 in, (401 mm) L x 11.5 in, (292 mm)W x 13.3 in, (338 mm) H Land Width: 0 in - 3/16 in (4.8 mm) in approximately 1/32 in(0.8 mm) increments Motor Type: Universal single-phase Motor RPM: 950 (no load) Body: Steel frame * Beveller cutting head and inserts are optimized for standard A53 mild steel pipe.Reduced insert life can be expected on other materials
Marketing Information
The B-500 Transportable Pipe Beveller produces high quality bevels in 45 seconds* without flames or sparks. The compact design quickly mounts to pipe 4" and up with a maximum wall thickness of 1/2", and creates consistent bevels in a single pass.
