Taco Comfort Solutions® 00 Series 006-IFC 006-BC7-1IFC Circulator Pump, 9 gpm, 115 V, 0.52 A, 60 Hz, 3250 rpm Motor
Taco Comfort Solutions® 00 Series 006-IFC 006-BC7-1IFC Circulator Pump, 9 gpm, 115 V, 0.52 A, 60 Hz, 3250 rpm Motor
Taco Comfort Solutions® Circulator Pump, 00 Series, Model: 006-IFC, 9 gpm Flow Rate, 9 ft Maximum Head, 115 V, 0.52 A, 60 Hz, 125 psi Maximum Pressure, 3250 rpm Motor Speed Rating, 1/40 hp, 1-1/2 in Connection, Sweat Connection, 1 ph Phase, 220 deg F, Bronze, 4-3/8 in H x 6 in W x 3-15/16 in D, Additional Information: Non-Metallic Impeller Material
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$664.00 / ea
In Stock
- Attributes
- Additional Information
- Features & Benefits
- Documents
- Marketing Information
Attributes
BrandTaco Comfort Solutions®
Additional InformationNon-Metallic Impeller Material
Amperage Rating0.52
Connection Size1-1/2
Connection TypeSweat
Dimensions4-3/8 " H x 6 " W x 3-15/16 " D
Flow Rate9
Frequency Rating60
HP Rating1/40
IndustryHydronics
MaterialBronze
Maximum Head9
Maximum Pressure125
Model006-IFC
Motor Speed Rating3250
Phase1
Series00 Series
Temperature Rating220
Voltage Rating115
Additional Information
cULus Listed|NSF Certified
Features & Benefits
- The IFC feature eliminates separate in-line flow check, reduces installation costs and improves system performance Unique replaceable cartridge design - field serviceable Unmatched reliability Quiet, efficient operation Self lubricating, no mechanical seal
Documents
Marketing Information
The compact Taco 006-IFC with an integral flow check is designed for circulating hot and chilled fresh water in open and closed loop applications. With its patented location at the impeller inlet, the IFC eliminates the added installation costs of a separate in-line flow check, simplifies piping and improves system performance. The unique, replaceable cartridge contains all moving parts and is easy to service instead of replacing the entire unit. It's self-lubricating, maintenance free design provides quiet, efficient operation and unmatched reliability.
Taco Comfort Solutions® 00 Series 006-IFC 006-BC7-1IFC Circulator Pump, 9 gpm, 115 V, 0.52 A, 60 Hz, 3250 rpm Motor
BrandTaco Comfort Solutions®
MFG #006-BC7-1IFC
