NIBCO F-918-B-2IN IB FLGD CHK VLV
NIBCO F-918-B-2IN IB FLGD CHK VLV
NIBCO® Horizontal Swing Check Valve, F-918-B Series, 2 in Nominal, Flanged Connection, 200 psi, Pressure Class: 125 lb, -20 to 150 deg F, Full Port, Steam Media, 8 in Inlet to Outlet Length, 3.94 in Top to Inlet Center, 6 in Opening, Iron Body, Brass Seat, Synthetic Fiber Seal, Brass Alloy Disc, Bronze Trim, Steel Softgoods, Contains Lead, 8 in L, Domestic/Import: Domestic
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$1,501.00 / ea
Out of Stock
- Attributes
- Additional Information
- Features & Benefits
- Documents
- Marketing Information
Attributes
BrandNIBCO®
Body MaterialIron
Connection TypeFlanged
Dimensions8 " L
Disc MaterialBrass Alloy
Domestic/ImportDomestic
IndustryPlumbing
Inlet to Outlet Length8
MediaSteam
Nominal Size2
Opening Size6
Port TypeFull
Pressure Class125
Pressure Rating200
Seal MaterialSynthetic Fiber
Seat MaterialBrass
SeriesF-918-B Series
Softgoods MaterialSteel
Temperature Rating-20 to 150
Top to Inlet Center3.94
Trim MaterialBronze
Additional Information
MSS SP-71
Features & Benefits
- Bolted bonnet Renewable seat and disc
Documents
Marketing Information
The NIBCO® cast iron horizontal swing check valve is designed with renewable seat and disc. The swing check valve prevents backflow by automatically closing when fluid reverses direction. The check valve is recommended for commercial and industrial steam, water, oil and gas services. The valve is class 125 flanged iron body and bronze mounted trim (IBBM). The NIBCO® cast iron check valve features flanged end connections for easy installation. It is equipped with a bolted bonnet for maintenance accessibility. Swing checks may be installed in horizontal positions (or vertical with flow moving up). Choose NIBCO® check valves for the most specified, versatile and economical valve option in commercial, mechanical and industrial applications. NIBCO® check valves backed by the NIBCO® 5 Year 125% limited warranty.
