VBF-72-A1 Model

• One Piece, Chrome Plated Flush Connection Water Deflector to control the amount of water diverted from the flush 3/8" Elbow and Flex-bend Tube connection from Vacuum Breaker to wall Diverter Wall Flange and Fittings Chrome Plated Wall Flange and Fitting to connect 1/2" NPT pipe High Back Pressure Vacuum Breaker One-piece Bottom Hex Coupling Nut

VBF-72-A Vacuum Breaker Trap Primer. The Sloan® VBF-72-A Vacuum Breaker Trap Primer provides for a constant water seal in floor drains. Maintaining a trap seal prevents objectionable sewer gases from escaping into the air. Each time the Sloan® Flushometer is activated, a small amount of water is diverted to the floor drain (piping from Trap Primer to floor drain not supplied by Sloan). The VBF-72-A uses a patented Water Deflector that carefully regulates the amount of water diverted to the drain. This makes the VBF-72-A specially suited for use with both 1.6 gpf (6.0 Lpf) Low Consumption and 3.5 gpf (13.2 Lpf) Water Saver Flushometers.
