ASSE 1003

• Automatic pressure reset from fast-fill Easy external dial-up pressure setting Set pressure indicator Simple serviceability with the unique one-piece cartridge Internal check allows the cartridge to be replaced without draining the system Integral strainer 12 psi factory setting, 250 psi maximum inlet pressure Wetted Parts stainless steel, engineered plastics, bronze, EPDM seal cartridge

Taco self-compensating cartridge-style pressure reducing valve, sets a new standard for performance and serviceability. All the parts are contained in a one-piece cartridge which can be easily removed and serviced without reducing the system pressure. A fast-fill mode that automatically returns to the normal mode when the set pressure is reached and delivers increased flow to speed system fill times. The cartridge style pressure reducing valve unique dial-in pressure setting allows for easy adjustment throughout the 10 to 50 psi range, without the need for an external gauge. Quality features include a stainless steel spindle, integral stainless steel coaxial strainer and easy, dial-up pressure setting that eliminates pressure gauges.
