Bell & Gossett PL Series PL-75B 1BL035LF Circulator Pump, 115 VAC, 60 Hz, 150 psi Max Pressure, 3400 rpm Motor, Bronze
Bell & Gossett PL Series PL-75B 1BL035LF Circulator Pump, 115 VAC, 60 Hz, 150 psi Max Pressure, 3400 rpm Motor, Bronze
Bell & Gossett Circulator Pump, PL Series, Model: PL-75B, 115 VAC, 60 Hz, 150 psi Maximum Pressure, 3400 rpm Motor Speed Rating, 1/6 hp, 2 in Connection, Flanged Connection, 1 ph Phase, In-Line Mounting, 225 deg F, Bronze, 8-1/2 in H x 9-15/16 in W x 4-5/8 in D, Additional Information: Glass-Filled Noryl Impeller Material
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$3,501.20Â /Â ea
Out of Stock
- Attributes
- Additional Information
- Features & Benefits
- Documents
Attributes
BrandBell & Gossett
Additional InformationGlass-Filled Noryl Impeller Material
Connection Size2
Connection TypeFlanged
Dimensions8-1/2 " H x 9-15/16 " W x 4-5/8 " D
Frequency Rating60
HP Rating6-Jan
IndustryHydronics
MaterialBronze
Maximum Pressure150
ModelPL-75B
Motor Speed Rating3400
Mounting Type"-Line
Phase1
SeriesPL Series
Temperature Rating225
Voltage Rating115
Additional Information
CSA Certified|UL Listed
Features & Benefits
- The pumps shall be of the horizontal, permanently lubricated type, specifically designed and guaranteed for quiet operation The pumps shall have a steel shaft supported by permanently lubricated, sealed precision ball bearings The pumps are to be equipped with a water-tight seal to prevent leakage Mechanical seal faces to be carbon on silicon carbide The motor shall be non-overloading at any point on the pump performance curve The motor shall be of the drip-proof, sealed precision ball bearing, quiet operating construction The permanent split-capacitor motor shall be equipped with thermal overload protection The Series PL features a maintenance-free system, with a self-cleaning particle shield protects the shaft and bearings from system start-up debris Easily handles dirty water conditions 25% more efficient than competition Close coupled dry motor
Bell & Gossett PL Series PL-75B 1BL035LF Circulator Pump, 115 VAC, 60 Hz, 150 psi Max Pressure, 3400 rpm Motor, Bronze
BrandBell & Gossett
MFG #1BL035LF
Keller #37440
