FLAMEGUARD CP-025 2-1/2 CPVC SPRKLR PIP (60 FT PER BAG. QTY 4 15 FT PIECES)
FLAMEGUARD CP-025 2-1/2 CPVC SPRKLR PIP (60 FT PER BAG. QTY 4 15 FT PIECES)
Spears® FlameGuard® Fire Sprinkler Pipe, 2-1/2 in Nominal Pipe, 2-7/8 in Outside Diameter, 15 ft Length, 0.213 in Wall Thickness, 175 psi, Extruded Method of Manufacture, Material Standard: ASTM F442, CPVC, Orange, 150 deg F
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$21.81 / ft
In Stock
- Attributes
- Additional Information
- Features & Benefits
- Documents
- Marketing Information
Attributes
BrandSpears®
ColorOrange
IndustryFire Protection
Length15
MaterialCPVC
Material StandardASTM F442
Method of ManufactureExtruded
Nominal Pipe Size2-1/2
Outside Diameter2-7/8
Pressure Rating175
Temperature Rating150
Wall Thickness0.213
WarrantyLimited Lifetime
Additional Information
ASTM D1784/F438/F439/F442/F493|FM Approved|LPCB Certified|NFPA 13/13D/13R|NSF Certified|UL Listed
Features & Benefits
- Unlike metal systems, FlameGuard® CPVC products never rust, scale or pit and do not sustain biological growth a cause of microbiologically influenced corrosion (MIC) which can destroy metal fire sprinkler systems from the inside out The smooth-wall interior surfaces of FlameGuard® CPVC systems result in reduced friction loss over metal systems The design flow characteristics remain constant throughout the life of the product because there is no interior corrosion in the system due to microbiological activity FlameGuard® CPVC system installations significantly reduce costs over conventional metal piping by virtually eliminating prefabrication Systems can be fully installed on site using solvent cement joining methods FlameGuard® CPVC fire sprinkler products are UL listed for US and Canada applications for light hazard occupancies as defined in NFPA 13, residential occupancies up to and including four-stories as defined in NFPA 13R and residential occupancies for one and two family dwellings and manufactured homes as defined in NFPA 13D
Documents
Marketing Information
Spears® FlameGuard® CPVC fire sprinkler products provide a cost effective alternative to metal systems with advantages of high corrosion resistance, improved system hydraulics, ease of installation and quick assembly with readily available tools. CPVC fire sprinkler systems are based on proven products that have been in continuous service for over 40 years. Spears® FlameGuard® products are approved by UL, FM global, LPCB and certified by NSF international for potable water use. Check local codes for restrictions and limitations.
FLAMEGUARD CP-025 2-1/2 CPVC SPRKLR PIP (60 FT PER BAG. QTY 4 15 FT PIECES)
BrandSpears®
MFG #CP-025
Keller #418902
My Part ##
Last Ordered#
$21.81 / ft
