cULus Listed|HVI 2100 Certified

• FG Series features new longer duct connections for easier installation Straight-through airflow allows fans to be installed at any angle at any point along the ductwork Performance, efficiency, reliability, air tightness, ease of installation Powered by ebm-PAPST external rotor motorized impeller for excellent heat dissipation, even at low rpm Permanently lubricated sealed ball bearings for maintenance-free operation Automatic reset thermal overload protection 100% speed controllable External rotor enclosure Fan shall be supplied with externally-mounted electrical terminal box with pre-wired terminal strip connections, capacitor shall be located within electric terminal box Motorized impeller shall be an external rotor type, class B insulation, enclosed with permanent split capacitor, motor shall be a permanently sealed self-lubricating ball bearing type Motor shall be acceptable for continuous-duty Fan wheel shall be of the backward inclined centrifugal type with a well designed inlet venturi for maximum performance Motorized impeller shall be both statically and dynamically balanced as one integral unit to provide for vibration free performance Includes-mounting bracket One-phase

With the motor in the airstream, the fan provides constant dissipation of heat build-up that gives the fan first-in-class longevity and reliability backed by an industry leading warranty. The fan's motor bearings are permanently sealed and self-lubricating for maintenance-free life. The housing is manufactured from a two-piece stamped, galvanized construction. The unique, folded seam procedure by Fantech joins the two halves to give the fan a first-in-class, airtight seal. The airtight casing allows installation in duct connections and in wet room applications to be possible. Easy installation and reduced maintenance requirements ensure you stay within your budget and you finish your project on your time.
