VICF V012728CT1 1 1/4 FPV 728 UL/FM/ULC GXG T B012466GW2 350 PSI HW W/1/4 TAP
VICF V012728CT1 1 1/4 FPV 728 UL/FM/ULC GXG T B012466GW2 350 PSI HW W/1/4 TAP
Victaulic® FireLock™ Ball Valve, 728 Series, 1-1/4 in Nominal, Grooved Connection, Full Port, 365 psi, 7-1/4 in Inlet to Outlet Length, 2.61 in Top to Inlet Center, Handwheel Operator, Material Standard: ASTM B124, ASTM B16 C36000, Brass Body, TFE Seat, Stainless Steel Stem, Brass/Ductile Iron/Stainless Steel Trim, Brass Ball, TFE Softgoods, Finish: Chrome-Plated, 2.2 in OD x 4.95 in H x 4.86 in D
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$754.50 / ea
In Stock
- Attributes
- Additional Information
- Features & Benefits
- Documents
- Marketing Information
Attributes
BrandVictaulic®
Ball MaterialBrass
Body MaterialBrass
Connection TypeGrooved
Dimensions2.2 " OD x 4.95 " H x 4.86 " D
FinishChrome-Plated
Inlet to Outlet Length7-1/4
Material StandardASTM B124, ASTM B16 C36000
Nominal Size1-1/4
Operator TypeHandwheel
Port TypeFull
Pressure Rating365
Seat MaterialTFE
Series728 Series
Softgoods MaterialTFE
Stem MaterialStainless Steel
Top to Inlet Center2.61
Trim MaterialBrass/Ductile Iron/Stainless Steel
Additional Information
FM 1112|UL 1091|cUL Listed|LPBC Certified|VdS Approved
Features & Benefits
- Standard port and supervisory switch
Documents
Marketing Information
The series 728 FireLock™ valve is a full port, ball valve that is UL/FM-rated for 365 psi/25 bar service in all sizes (LPCB and VdS listed for 20 bar services). Available with grooved or threaded ends (NPT), the valve body is brass. The ball is chrome-plated brass with a stainless steel stem. Reinforced seats aid ease of operation and provide a durable, corrosion-free seat. Flow characteristics exceed UL specification 1091 and FM approval standard 1112. The valve is approved for indoor and outdoor use.
VICF V012728CT1 1 1/4 FPV 728 UL/FM/ULC GXG T B012466GW2 350 PSI HW W/1/4 TAP
BrandVictaulic®
MFG #V012728CT1
Keller #491028
My Part ##
Last Ordered#
$754.50 / ea
