VICF V014728CT0 1 1/2 FPV 728 UL/FM/ULC TXT T B014466TW2 HW FIRELOCK VALVE
VICF V014728CT0 1 1/2 FPV 728 UL/FM/ULC TXT T B014466TW2 HW FIRELOCK VALVE
Victaulic® FireLock™ Ball Valve, 728 Series, 1-1/2 in Nominal, FNPT Connection, Full Port, 365 psi, 3.66 in Inlet to Outlet Length, Material Standard: ASTM B124, Brass Body, Carbon Tetrafluoroethylene Seat, Stainless Steel Stem, Brass/Stainless Steel Trim, Carbon Filled TFE Softgoods, Finish: Chrome-Plated, 5.13 in H x 4.86 in W
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$966.50 / ea
Out of Stock
- Attributes
- Additional Information
- Features & Benefits
- Documents
- Marketing Information
Attributes
BrandVictaulic®
Body MaterialBrass
Connection TypeFNPT
Dimensions5.13 " H x 4.86 " W
FinishChrome-Plated
Inlet to Outlet Length3.66
Material StandardASTM B124
Nominal Size1-1/2
Port TypeFull
Pressure Rating365
Seat MaterialCarbon Tetrafluoroethylene
Series728 Series
Softgoods MaterialCarbon Filled TFE
Stem MaterialStainless Steel
Trim MaterialBrass/Stainless Steel
Additional Information
cULus Listed|FM Class 1112|LPCB Approved|VdS Approved|UL 1091
Features & Benefits
- Standard port and supervisory switch
Documents
Marketing Information
The Series 728 FireLock valve is a full port, ball valve that is UL/FM-Rated for 365 psi/25 bar service in all sizes (LPCB and VdS Listed for 20 BAR services). Available with grooved or threaded ends (NPT), the valve body is brass. The ball is chrome-plated brass with a stainless steel stem. Reinforced seats aid ease of operation and provide a durable, corrosion-free seat. Flow characteristics exceed UL Specification 1091 and FM Approval Standard 1112. The valve is approved for indoor and outdoor use.
