Sioux Chief TurboVent™ 250 Series 250-696122P Air Admittance Valve, 1-1/2 x 2 in, Hub, 20/160 DFU, 8/24 DFU, SCH 40
Sioux Chief TurboVent™ 250 Series 250-696122P Air Admittance Valve, 1-1/2 x 2 in, Hub, 20/160 DFU, 8/24 DFU, SCH 40
Sioux Chief TurboVent™ Air Admittance Valve, 250 Series, 1-1/2 x 2 in Connection, Hub Connection, DFU Rating: 20/160 DFU, 8/24 DFU, 13 psig, SCH 40, -40 to 150 deg F, ABS, White, 2-1/8 in Overall Length, 2-3/4 in Overall Width, Domestic/Import: Domestic
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$35.14 / ea
In Stock
- Attributes
- Additional Information
- Features & Benefits
- Documents
- Marketing Information
Attributes
BrandSioux Chief
ColorWhite
Connection Size1-1/2 x 2
Connection TypeHub
DFU Rating20/160 DFU, 8/24 DFU
Domestic/ImportDomestic
IncludesDual Fit Adapter and OxBox Kit
MaterialABS
Overall Length2-1/8
Overall Width2-3/4
Pressure Rating13
Schedule RatingSCH 40
Series250 Series
Temperature Rating-40 to 150
Additional Information
ASSE 1050, 1051|IPC 2021 918.1|IRC 2021 P3114.1|IAPMO Approved|UPC 2021 Section 301.3
Features & Benefits
- Air admittance valve opens during drainage, then seals tight after ABS access box with frame and louvered cover provides air flow and allows for inspection and maintenance Paintable frame and cover
Marketing Information
Sioux Chief 250 Series TurboVent™ air admittance valves with fire-rated access box shall be installed as vent terminal for secondary venting within the plumbing system. Valve shall connect to DWV system via SCH 40 adapter and be made accessible after finish wall is installed. Valve shall incorporate an actuating device which spins upon activation to keep the elastomeric sealing surface clean and free of debris. During drainage, actuating device shall raise a designed distance under negative line pressure to allow optimal air flow into the DWV system. Valve shall provide a positive seal at 0 psi and under any positive line pressure to prevent sewer gasses from entering the living space.
Sioux Chief TurboVent™ 250 Series 250-696122P Air Admittance Valve, 1-1/2 x 2 in, Hub, 20/160 DFU, 8/24 DFU, SCH 40
BrandSioux Chief
MFG #250-696122P
Keller #618858
