SIGMA PIPE 1FLB0014 STEEL PLATE 6 BLIND FLANGE (SIZE 11)
SIGMA PIPE 1FLB0014 STEEL PLATE 6 BLIND FLANGE (SIZE 11)
SIGMA Piping Products™ Blind Plate Flange, Flange Fitting, 6 in Connection Size 1, 6 in Connection Size 2, Steel, Steel Material Construction, 0.69 in Flange Thickness, 8 Bolt Holes, 7/8 in Bolt Hole Dia, Pressure Class: 125 lb, 175 psi, 11 in OD, Additional Information: 9-1/2 in Bolt Circle
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$115.80Â /Â ea
In Stock
- Attributes
- Additional Information
- Features & Benefits
- Documents
Attributes
BrandSIGMA PIPING PRODUCTS
Bolt Hole Diameter7/8"
Connection Size 16"
Connection Size 26"
Dimensions11" OD
Fitting TypeFlange
Flange Thickness0.69"
IndustryFire Protection
MaterialSteel
Material ConstructionSteel
Number of Bolt Holes8
Pressure Class125 lb
Pressure Rating175 psi
Additional Information
9-1/2 in Bolt Circle
Features & Benefits
- Bolts shall be smaller in diameter than the normal bolt hole diameter
- These flanges have the same diameter and drilling as class 125 cast iron flanges (ANSI B16.1)
- Minimum bolt lengths shall be the sum of the mating flange maximum thicknesses, the gasket and the depth of the nut plus 1/8 in minimum before torquing if threaded rods are used, they shall be the same length as the bolts determined previously, plus the depth of the nuts
