ARMSTRONG E.2 Series 182212-842 Circulator, 50 gpm, 300 W, 120 V, 4.8 A, 60 Hz, 150 psi Max Pressure, 3300 rpm Motor
ARMSTRONG E.2 Series 182212-842 Circulator, 50 gpm, 300 W, 120 V, 4.8 A, 60 Hz, 150 psi Max Pressure, 3300 rpm Motor
ARMSTRONG Circulator, Series: E.2 Series, Model: E12.2b, 50 gpm Flow Rate, 56 ft Maximum Head, 300 W, 120 V, 4.8 A, 60 Hz, 150 psi Maximum Pressure, 3300 rpm Motor Speed Rating, 2/5 hp, 1-1/4 in Connection, 2-Bolt Flange Connection, 1 ph, 2 Poles, 230 deg F, Bronze, 9.3 in L x 6.4 in H
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
Call for Price / ea
Out of Stock
- Attributes
- Additional Information
- Features & Benefits
- Documents
- Marketing Information
Attributes
BrandARMSTRONG
Amperage Rating4.8
Connection Size1-1/4
Connection Type2-Bolt Flange
Dimensions9.3 " L x 6.4 " H
Flow Rate50
Frequency Rating60
HP Rating2/5
IndustryPlumbing
MaterialBronze
Maximum Head56
Maximum Pressure150
ModelE12.2b
Motor Speed Rating3300
Number of Poles2
Phase1
Power Rating300
SeriesE.2 Series
Temperature Rating230
Voltage Rating120
Additional Information
cULus Listed|NSF 372
Features & Benefits
- Easy installation and upgrades - compact design minimizes flange to flange dimensions and spool pieces provide compatibility with a wide range of competing circulators Leading-duty point efficiency - advanced, high efficiency dry motor and efficient hydraulics design Long term performance - lasting components and refined product design for extended durability and low lifetime cost Easy maintenance and repair - easy access to mechanical seal and seal replacement in less than 5 min
Marketing Information
The ARMSTRONG E.2 circulators draw on advanced motor technology and efficient hydraulic design to achieve excellent wire-to-water duty point efficiencies.
ARMSTRONG E.2 Series 182212-842 Circulator, 50 gpm, 300 W, 120 V, 4.8 A, 60 Hz, 150 psi Max Pressure, 3300 rpm Motor
BrandARMSTRONG
MFG #182212-842
Keller #690932
