NIBCO W910W-LF-10IN CI CHECK VLV
NIBCO W910W-LF-10IN CI CHECK VLV
NIBCO® Silent Check Valve, 10 in Nominal, Wafer Connection, 200 psi, Pressure Class: 125 lb, 200 deg F, 8-1/4 in Inlet to Outlet Length, Iron Body, Bronze Seat, Bronze Disc, Lead-Free, 16 in L x 16 in W x 8-1/4 in H, Domestic/Import: Domestic
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$11,028.00 / ea
Out of Stock
- Attributes
- Additional Information
- Features & Benefits
- Documents
- Marketing Information
Attributes
BrandNIBCO®
Body MaterialIron
Connection TypeWafer
Dimensions16 " L x 16 " W x 8-1/4 " H
Disc MaterialBronze
Domestic/ImportDomestic
IndustryPlumbing
Inlet to Outlet Length8-1/4
Lead-FreeYes
Nominal Size10
Pressure Class125
Pressure Rating200
Seat MaterialBronze
Temperature Rating200
Additional Information
FM Approved|MSS SP-125|NSF/ANSI/CAN 61/372
Features & Benefits
- Valve pressure rating 200 psi/13.8 bar non-shock cold working pressure
- Maximum temperature 180 degreeF/ 82 degreeC
- Renewable seat and disc
- Spring actuated (1/2 psi cracking pressure)
- Class 125 wafer end connections
- Lead-free
- Conforms to MSS SP-125
- NSF/ANSI/CAN-61 and 372
Documents
Marketing Information
The NIBCO® cast iron sliding disc check valve is wafer style to fit between standard flanges. Wafer checks may be installed in horizontal positions (or vertical with flow moving up). Please refer to NIBCO technical data sheets, chemical-resistance guides and catalogs for engineering and installation information. Choose NIBCO® check valves for the most specified, versatile and economical valve option in commercial, mechanical and industrial applications.
NIBCO W910W-LF-10IN CI CHECK VLV
BrandNIBCO®
MFG #NLN20XM
Keller #703228
My Part ##
Last Ordered#
$11,028.00 / ea
