Honeywell

Honeywell MS4105A1030/U Damper Actuator, 100 - 250 VAC, 45 sec Nominal at 60 Hz Driving, 25 sec Spring Return Timing

Honeywell MS4105A1030/U Damper Actuator, 100 - 250 VAC, 45 sec Nominal at 60 Hz Driving, 25 sec Spring Return Timing
Honeywell

Honeywell MS4105A1030/U Damper Actuator, 100 - 250 VAC, 45 sec Nominal at 60 Hz Driving, 25 sec Spring Return Timing

MFG #MS4105A1030/U

Item #715420

Mfr. Part #MS4105A1030/U

UPC #085267505260

Honeywell Damper Actuator, 100 - 250 VAC, 50/60 Hz, 6/9 V-A Driving VA, Enclosed Screw Terminal Strip (22 - 14 AWG) Electrical Connection, 45 sec Nominal at 60 Hz Driving, 25 sec Spring Return Timing, Plastic, 44 in-lb Torque, 95 kohm Minimum Input, 50 dBA Driving, 20 dBA Holding, -22 to 149 deg F Ambient, NEMA 2, IP54 Enclosure, 5 - 95% RH Non-Condensing Humidity, 3-55/84 in W x 6-81/54 in H x 3-5/32 in D, 2-Position SPST Control Signal, Direct Coupled Mounting, 3/8 - 5/8 in Round or 1/4 - 1/2 in Square Shaft, 95 +/-3 deg Stroke

Why Create an Account?

  • Ability to track orders
  • More Options & Savings
  • Amazing Customer Service
$491.39 / ea
Out of Stock
Attributes
BrandHoneywell
ApplicationFor HVAC systems
Control Signal2-Position SPST
Dimensions3-55/84 " W x 6-81/54 " H x 3-5/32 " D
Electrical ConnectionEnclosed Screw Terminal Strip (22 - 14 AWG)
Enclosure TypeNEMA 2, IP54
Frequency Rating50/60
Humidity Rating5 - 95% RH Non-Condensing
IncludesMounting Bracket, Self-Centering Shaft Adapter
IndustryHVAC
Input Impedance95 kohm Minimum
MaterialPlastic
Mounting TypeDirect Coupled
Noise Level50 dBA Driving, 20 dBA Holding
Shaft Size3/8 - 5/8 " Round or 1/4 - 1/2 " Square
Stroke95 +/-3 deg
Temperature Rating-22 to 149 deg F Ambient
Timing Range45 sec Nominal at 60 Hz Driving, 25 sec Spring Return
Torque Rating44
VA Rating6/9 V-A Driving
Voltage Rating100 - 250
Honeywell MS4105A1030/U Damper Actuator, 100 - 250 VAC, 45 sec Nominal at 60 Hz Driving, 25 sec Spring Return Timing
Honeywell MS4105A1030/U Damper Actuator, 100 - 250 VAC, 45 sec Nominal at 60 Hz Driving, 25 sec Spring Return Timing
BrandHoneywell
MFG #MS4105A1030/U
Keller #715420
My Part ##
Last Ordered#
Price
$491.39 / ea
