Apollo® Apollo International™ 94ALF-A Series 94ALF-209-01A Ball Valve, 2-1/2 in, Solder, Brass, 400 psi
Apollo® Apollo International™ 94ALF-A Series 94ALF-209-01A Ball Valve, 2-1/2 in, Solder, Brass, 400 psi
Apollo® Apollo International™ Ball Valve, 94ALF-A Series, 2-1/2 in Nominal, Solder Connection, Full Port, 2-Piece, 400 psi, Fire, Fuel, Gas, Water Media, 2.52 in Orifice, 6.28 in Inlet to Outlet Length, 4.66 in Top to Inlet Center, 2.63 in Opening, Lever Handle Operator, Brass Body, PTFE Seat, Brass Stem, PTFE Seal, Brass/EPDM/PTFE Trim, PTFE Packing, PVC/Steel Handle, 316 Stainless Steel Ball, EPDM/PTFE Softgoods, Lead-Free, Brass, 0 to 400 deg F, 6.28 in L, Domestic/Import: Import
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$1,372.01 / ea
In Stock
- Attributes
- Additional Information
- Features & Benefits
- Documents
- Marketing Information
Attributes
BrandApollo®
ApplicationFor potable water, heating and cooling applications
Ball Material316 Stainless Steel
Body MaterialBrass
ColorBrass
Configuration2-Piece
Connection TypeSolder
Dimensions6.28 " L
Domestic/ImportImport
Handle MaterialPVC/Steel
IndustryPlumbing
Inlet to Outlet Length6.28
Lead-FreeYes
MediaFire, Fuel, Gas, Water
Nominal Size2-1/2
Opening Size2.63
Operator TypeLever Handle
Orifice Size2.52
Packing MaterialPTFE
Port TypeFull
Pressure Rating400
Seal MaterialPTFE
Seat MaterialPTFE
Series94ALF-A Series
Softgoods MaterialEPDM/PTFE
Stem MaterialBrass
Temperature Rating0 to 400
Top to Inlet Center4.66
Trim MaterialBrass/EPDM/PTFE
Warranty5 Year
Shipping Dimensions (L x W x H)12" x 4.25" x 6.5"
Additional Information
ANSI Z1157|cCSAus Certified|cUPC Certified|EU Directive 2015/863 (RoHS 3)|EU Regulation (EC) 1907/2006 (REACH)|FM Approved|IAPMO Approved|MSS-SP-110|NSF/ANSI/CAN 61, 372|UL Listed
Features & Benefits
- EZ-Solder™ lead-free materials Distinctive white lead-free handle grip Blowout-proof stem 100% factory tested Adjustable stem packing nut Multiple agency approvals Stem seal O-ring
Documents
Marketing Information
The Apollo® International™ 94ALF-A lead-free forged brass ball valve combines reliable operation with maximum economy. Featuring multi-agency approvals, the 94ALF-A is ideal for gas, fuels, fire protection and general plumbing and HVAC applications including potable water. Valves are ANSI third party lead-free certified.
