Yellow Jacket® 69086 Vacuum Gauge, 3-1/8 in Dial, +/-20 % Accuracy, Male Flared
Yellow Jacket® 69086 Vacuum Gauge, 3-1/8 in Dial, +/-20 % Accuracy, Male Flared
Yellow Jacket® Vacuum Gauge, 3-1/8 in Dial, +/-20 % Accuracy, Male Flared Connection, R-22, R-410A Refrigerant, 450 psi, Coin Cell Battery, LCD Display, 32 to 122 deg F, ABS, 13 in L x 11 in W x 2 in H, Additional Information: D Battery Size
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$880.17 / ea
Out of Stock
- Attributes
- Additional Information
- Features & Benefits
- Documents
- Marketing Information
Attributes
BrandYellow Jacket®
Accuracy+/-20
Additional InformationD Battery Size
Battery TypeCoin Cell
Connection TypeMale Flared
Dial Size3-1/8
Dimensions13 " L x 11 " W x 2 " H
Display TypeLCD
IncludesFabric Carry Pouch
IndustryHVAC
Map314.91
MaterialABS
Pressure Rating450
Refrigerant TypeR-22, R-410A
Temperature Rating32 to 122
Shipping Dimensions (L x W x H)12" x 10.3" x 1"
Additional Information
CE Marked|NIST Approved
Features & Benefits
- Unique patented thermal conductivity sensor automatically compensates for temperature Replaceable, cleanable, plug-in sensor (part no. 69087) handles 450 psi positive pressure Displays 7 different units of vacuum (microns, millitorr, torr, millimeters of mercury, millibar, kilopascal and pascal) 12 in coiled sensor cord stretches to 24 in for easy reach, connectivity and readability of display Magnetized on back for secure, upright positioning on any magnetized surface Low battery indicator Automatic shut-off after 20 min Calibration standards traceable to NIST 14 oz with battery
Documents
Marketing Information
Each displays down from atmosphere to 10 um (bar graph indication above 25000 um) of vacuum to let you know that your vacuum pump is clean and performing properly. If the sensor gets dirty, simply plug a new sensor into the gauge, run through a quick calibration process and be back on the job within minutes. Seven units of vacuum for confidence. This easy to use gauge shows that air and moisture have been removed from the system. A simple push of a button changes the display readout between 7 units of vacuum.
Yellow Jacket® 69086 Vacuum Gauge, 3-1/8 in Dial, +/-20 % Accuracy, Male Flared
BrandYellow Jacket®
MFG #69086
Keller #791136
