Lochinvar® FTXL™ Fire Tube Boiler FTX725 FTX725-N Boiler With Control and Safety Device, Up to 98.3 % AFUE, 120 V, NPT
Lochinvar® FTXL™ Fire Tube Boiler FTX725 FTX725-N Boiler With Control and Safety Device, Up to 98.3 % AFUE, 120 V, NPT
Lochinvar® FTXL™ Fire Tube Boiler Boiler With Control and Safety Device, Model: FTX725, 120 V, 6 A, 21.7 hp Power, 60 Hz Frequency, 1 ph, Up to 98.3 % AFUE, 725000 Btu/hr BTU, 17 gal Capacity, 71 gpm Flow Rate, 160 psi Pressure, NPT Connection, Natural Gas Fuel, Direct Vent, Modulating Burner, CFM Rating: 150 cfm, Chimney/Breeching/Vent Size: 6 in, 705000 Btu/hr DOE Heating, Ignition System: Direct Spark, Direct Spark Ignition, Net BTU Rating: 613 mbh, 84.6 sq-ft Area, Wall Mounting, Stainless Steel, Dimensions: 53-1/4 in H x 26-1/4 in W x 23-1/2 in D, Additional Information: 1 in Gas Connection, 2-1/2 in Water Connection
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$32,931.00 / ea
In Stock
- Attributes
- Additional Information
- Features & Benefits
- Documents
Attributes
BrandLochinvar®
Additional Information1 " Gas Connection, 2-1/2 " Water Connection
AFUE RatingUp to 98.3
Amperage Rating6
Area84.6
BTU Rating725000
Burner TypeModulating
Capacity17
CFM Rating150
Chimney/Breeching/Vent Size6
Connection TypeNPT
Dimensions53-1/4 " H x 26-1/4 " W x 23-1/2 " D
DOE Heating Capacity705000
Flow Rate71
Frequency Rating60
Fuel TypeNatural Gas
Ignition SystemDirect Spark
Ignition TypeDirect Spark
IndustryHydronics
MaterialStainless Steel
ModelFTX725
Mounting TypeWall
Net BTU Rating613
Phase1
Power Rating21.7
Pressure Rating160
Vent TypeDirect
Voltage Rating120
Additional Information
AHRI Certified|ASME Specified|CSA Certified|ENERGY STAR Certified
Features & Benefits
- CON-X-US remote connect Smart touch touchscreen operating control Full color 7 in touchscreen LCD display Cascading sequencer with built-in redundancy Three-reset temperatures inputs with independent outdoor reset curves for each Four pump control Building management system integration Programmable system efficiency optimizers High voltage terminal strip Low voltage terminal strip Time clock Data logging Modulating burner with up to 10:1 turndown On/Off switch Adjustable high limit with manual reset Automatic reset high limit Manual reset low water cut-off Flue temperature sensor Low air pressure switch Temperature and pressure gauge
Lochinvar® FTXL™ Fire Tube Boiler FTX725 FTX725-N Boiler With Control and Safety Device, Up to 98.3 % AFUE, 120 V, NPT
BrandLochinvar®
MFG #FTX725N-M13
Keller #796943
My Part ##
Last Ordered#
$32,931.00 / ea
