Lochinvar® FTXL™ FTX850N-M13 Fire Tube Boiler, 121.4 to 850 mbh BTU, 16 gal Capacity, 120 VAC, 1 ph Phase, NPT
Lochinvar® FTXL™ FTX850N-M13 Fire Tube Boiler, 121.4 to 850 mbh BTU, 16 gal Capacity, 120 VAC, 1 ph Phase, NPT
Lochinvar® FTXL™ Fire Tube Boiler, 120 VAC, 8 A, 60 Hz Frequency, 1 ph, 121.4 to 850 mbh BTU, 16 gal Capacity, 25 to 150 gpm Flow Rate, 160 psi Pressure, NPT Connection, Natural Fuel, Direct Vent, Chimney/Breeching/Vent Size: 6 in, Direct Spark Ignition, 99.88 sq-ft Area, Stainless Steel, Dimensions: 53-1/4 in H x 26-1/4 in W x 23-1/2 in D, Additional Information: CSD-1/FM/GE Gap Firing Control
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$37,664.00 / ea
Out of Stock
- Attributes
- Features & Benefits
- Documents
- Marketing Information
Attributes
BrandLochinvar®
Additional InformationCSD-1/FM/GE Gap Firing Control
Amperage Rating8
Area99.88
BTU Rating121.4 to 850
Capacity16
Chimney/Breeching/Vent Size6
Connection TypeNPT
Dimensions53-1/4 " H x 26-1/4 " W x 23-1/2 " D
Flow Rate25 to 150
Frequency Rating60
Fuel TypeNatural
Ignition TypeDirect Spark
IndustryPlumbing
MaterialStainless Steel
Phase1
Pressure Rating160
Vent TypeDirect
Voltage Rating120
Features & Benefits
- Up to 98.3% thermal efficiency Up to 10:1 turn down ratio Features CON-X-US® remote connectivity and SMART TOUCH™ operating control
Marketing Information
For light commercial applications, the FTXL™ brings models from 399000 to 999000 Btu/hr and takes Lochinvar's fire-tube technology to the next level.
Lochinvar® FTXL™ FTX850N-M13 Fire Tube Boiler, 121.4 to 850 mbh BTU, 16 gal Capacity, 120 VAC, 1 ph Phase, NPT
BrandLochinvar®
MFG #FTX850N-M13
Keller #816193
My Part ##
Last Ordered#
$37,664.00 / ea
