NIBCO LD2000-3-2IN LUG BFLY VLV
NIBCO LD2000-3-2IN LUG BFLY VLV
NIBCO® Butterfly Valve, LD-2000-3 Series, 2 in Nominal, Lug Connection, 200 psi, Water Media, 6.38 in Top to Inlet Center, Ductile Iron Body, EPDM Seat, Stainless steel Stem, EPDM Seal, Aluminum Bronze Disc, EPDM Softgoods, Lever Lock Handle Operator, 225 deg F, Material Standard: ASTM A582, ASTM B16, ASTM B148, ASTM A536, Lead-Free, 9.26 in H x 13.38 in W x 4.63 in D, Domestic/Import: Domestic
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$639.00 / ea
In Stock
- Attributes
- Additional Information
- Features & Benefits
- Documents
- Marketing Information
Attributes
BrandNIBCO®
ApplicationFor commercial and some light industrial process applications, including HVAC and vacuum services, in addition to hot and cold potable water
Body MaterialDuctile Iron
Connection TypeLug
Dimensions9.26 " H x 13.38 " W x 4.63 " D
Disc MaterialAluminium Bronze
Domestic/ImportDomestic
IndustryPlumbing
Lead-FreeYes
Material StandardASTM A582, ASTM B16, ASTM B148, ASTM A536
MediaWater
Nominal Size2
Operator TypeLever Lock Handle
Pressure Rating200
Seal MaterialEPDM
Seat MaterialEPDM
SeriesLD-2000-3 Series
Softgoods MaterialEPDM
Stem MaterialStainless Steel
Temperature Rating225
Top to Inlet Center6.38
Warranty5 Year Limited
Additional Information
API 609 Approved|California Health and Safety Code Section 116875|MSS SP-25 Certified|MSS SP-67 Certified|ANSI/NSF 61/8/61/372 Certified|Vermont Act 193
Features & Benefits
- EPDM molded in seat liner Stainless steel stem with copper bushings Bare stem, infinite position plate and lock, lever lock, manual gear operator and pneumatic/electric automation Install between standard ASME class 125/150 flanges
Documents
Marketing Information
The NIBCO® ductile iron lug butterfly valve provides ease of operation with quarter-turn (90 deg) open to close. With the internal stem/disc geometric drive design, there is no need for pins or bolts that may create leak paths or turbulence in the waterway. An extended neck allows for insulation up to 2 in. The unique molded in EPDM seat liner with aluminum bronze disc is recommended for most water applications. Choose NIBCO® butterfly valves for the most specified, versatile and economical valve option in commercial, mechanical and industrial applications. NIBCO® butterfly valves are backed by the NIBCO® 5 year 125% limited warranty.
NIBCO LD2000-3-2IN LUG BFLY VLV
BrandNIBCO®
MFG #NLG100D
Keller #85572
My Part ##
Last Ordered#
$639.00 / ea
