Bell & Gossett ecocirc® XL Series ecocirc XL B 36-45 104401LF Circulating Pump, 20 to 200 W, 115 V, 0.1 to 3 A, 50/60 Hz
Bell & Gossett ecocirc® XL Series ecocirc XL B 36-45 104401LF Circulating Pump, 20 to 200 W, 115 V, 0.1 to 3 A, 50/60 Hz
Bell & Gossett Circulating Pump, Series: ecocirc® XL, Model: ecocirc XL B 36-45, 1-1/2 in Outlet, 20 to 200 W, 115 V, 0.1 to 3 A, 50/60 Hz, 175 psi Maximum, 1500 to 4450 rpm Motor Speed Rating, HP Rating: 1/6 hp, 1-1/2 in, NPT, 1, 14 to 230 deg F, IP44, Sleeve Bearing, Bronze, 6.38 in H x 9.94 in W x 7.2 in D, Additional Information: 6-3/8 in Port to Port, 2-Bolt Holes, 32 to 104 deg F Ambient Temperature, Class F Motor Insulation, EPDM Gasket/O-Ring
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$2,508.91 / ea
Out of Stock
- Attributes
- Additional Information
- Documents
- Marketing Information
Attributes
BrandBell & Gossett
Additional Information6-3/8 " Port to Port, 2-Bolt Holes, 32 to 104 deg F Ambient Temperature, Class F Motor Insulation, EPDM Gasket/O-Ring
Amperage Rating0.1 to 3
Bearing TypeSleeve
Connection Size1-1/2
Connection TypeNPT
Dimensions6.38 " H x 9.94 " W x 7.2 " D
Enclosure TypeIP44
Frequency Rating50/60
HP Rating1/6
IndustryPlumbing
MaterialBronze
Maximum Pressure175
Modelecocirc XL B 36-45
Motor Speed Rating1500 to 4450
Outlet Size1-1/2
Phase1
Power Rating20 to 200
Seriesecocirc XL
Temperature Rating14 to 230
Voltage Rating115
Additional Information
CSA Certified|cULus C22.2 File No. 108|NSF/ANSI 372|UL 1004-1|UL 1004-7|UL 60730-1|UL 778
Marketing Information
The ecocirc® XL circulator is designed with a highly efficient electronically commutated permanent magnet motor (ECM/PM Technology). Cast iron body designed for closed loop hydronic heating and cooling systems pumping water or water/glycol mix. Lead-free bronze body designed for plumbing systems or open loop heating and cooling systems.
Bell & Gossett ecocirc® XL Series ecocirc XL B 36-45 104401LF Circulating Pump, 20 to 200 W, 115 V, 0.1 to 3 A, 50/60 Hz
BrandBell & Gossett
MFG #104401LF
Keller #942285
My Part ##
Last Ordered#
$2,508.91 / ea
