Grundfos B 30SQ10-130 Submersible Groundwater Pump, 30.8 gpm, 11.2 A, 200-240 V, 2.08 hp, 1 ph
Grundfos B 30SQ10-130 Submersible Groundwater Pump, 30.8 gpm, 11.2 A, 200-240 V, 2.08 hp, 1 ph
Grundfos Submersible Groundwater Pump, Model: B, 1-1/2 in Suction, 1-1/2 in Discharge, 30.8 gpm Flow Rate, 11.2 A, 200-240 V, 2.08 hp, 1 ph Phase, 60 Hz, 10700 rpm, Maximum Feet of Head: 121.4 ft, 4.92 ft Cord Length, 95 deg F Maximum Temperature, 217.56 psi Working Pressure, Composite Impeller, 304 Stainless Steel Body, Polyethylene/Stainless Steel, 35 in H x 2.9 in Dia, Additional Information: 3-Stage, 62.29 lb/cu-ft Density, 2.05 kW Power
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$2,356.00Â /Â ea
Out of Stock
- Attributes
- Additional Information
- Features & Benefits
- Documents
- Marketing Information
Attributes
BrandGrundfos
Additional Information3-Stage, 62.29 lb/cu-' Density, 2.05 kW Power
Amperage Rating11.2
Body Material304 Stainless Steel
Cord Length4.92
Dimensions35 " H x 2.9 " Dia
Discharge Size1-1/2
Flow Rate30.8
Frequency Rating60
HP Rating2.08
Impeller MaterialComposite
IndustryPlumbing
MaterialPolyethylene/Stainless Steel
Maximum Feet of Head121.4
Maximum Temperature95
ModelB
Phase1
Speed Rating10700
Suction Size1-1/2
Voltage Rating200-240
Working Pressure217.56
Additional Information
cULus Listed|DIN W.-Nr. 1.4301|EN 1.4301
Features & Benefits
- Dry-run protection High-efficiency pump and motor Protection against upthrust Soft-start Over voltage and under voltage protection Over temperature protection High starting torque Insulation Class F CU 300/CU 301 controls
Documents
Marketing Information
At only 3 in Dia, the Grundfos SQ submersible pump is extremely compact and ideal for small or restricted wells. In addition to the features and benefits shared with the renowned SP submersible pump, the SQ offers a number of motor protection and wear-reducing features that makes it the obvious choice for groundwater pumping. Suitable for domestic or small waterworks and small irrigation systems.
Grundfos B 30SQ10-130 Submersible Groundwater Pump, 30.8 gpm, 11.2 A, 200-240 V, 2.08 hp, 1 ph
BrandGrundfos
MFG #96160161
