Apollo® 36E Series 36ELF11701T Water Pressure Reducing Valve, 1-1/2 in Nominal, Union FNPT x FNPT, 172 gpm, 15 to 75 psi
Apollo® 36E Series 36ELF11701T Water Pressure Reducing Valve, 1-1/2 in Nominal, Union FNPT x FNPT, 172 gpm, 15 to 75 psi
Apollo® Water Pressure Reducing Valve, 36E Series, 1-1/2 in Nominal, Union FNPT x FNPT Connection, 15 to 75 psi, 172 gpm Flow Rate, Water Media, 8.1 in Inlet to Outlet Length, Material Standard: ASTM B16, ASTM B228, ASTM B584, Bronze Body, EPDM Disc, EPDM Softgoods, Lead-Free, Yellow, 33 to 180 deg F, 3.38 in Dia x 10 in H, Domestic/Import: Domestic, Additional Information: 400 psig Maximum Supply Pressure, Direct Acting
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$912.49 / ea
In Stock
- Attributes
- Additional Information
- Features & Benefits
- Documents
- Marketing Information
Attributes
BrandApollo®
Additional Information400 psig Maximum Supply Pressure, Direct Acting
ApplicationFor potable water applications
Body MaterialBronze
ColorYellow
Connection TypeUnion FNPT x FNPT
Dimensions3.38 " Dia x 10 " H
Disc MaterialEPDM
Domestic/ImportDomestic
Flow Rate172
Inlet to Outlet Length8.1
Material StandardASTM B16, ASTM B228, ASTM B584
MediaWater
Nominal Size1-1/2
Pressure Rating15 to 75
Series36E Series
Softgoods MaterialEPDM
Temperature Rating33 to 180
Warranty5 Year
Shipping Dimensions (L x W x H)6.8" x 10" x 3.38"
Additional Information
ARRA Compliant|ASSE 1003|ASTM F1960|Buy America Act Compliant|Buy America Act Compliant|CSA B356|IAPMO/UPC Certified|NSF Certified
Features & Benefits
- Balanced piston design Stainless steel adjusting screw and nut Sealed cage for vault installations Built-in thermal expansion bypass Large area integral stainless steel strainer Modular seat disc and strainer cartridge Factory tested and preset at 60 psi High flow/high efficiency design 100% manufactured in USA
Documents
Marketing Information
The Apollo® 36ELF Series lead-free pressure reducing valve is designed to conserve water and protect water distribution systems by automatically reducing elevated supply pressures. The dezincification-resistant bronze body, stainless steel adjusting screw and dielectric polymer cage provide maximum corrosion resistance. Designed for easy in-line servicing with simple cartridge removal.
Apollo® 36E Series 36ELF11701T Water Pressure Reducing Valve, 1-1/2 in Nominal, Union FNPT x FNPT, 172 gpm, 15 to 75 psi
BrandApollo®
MFG #36ELF11701T
Keller #956195
