Samsung Smart Pearl AR12 AR12KSWDHWKXCV Heat Pump Split System Outdoor Unit, 208 - 230 V, 12000 Btu/hr Cooling, Steel
Samsung Smart Pearl AR12 AR12KSWDHWKXCV Heat Pump Split System Outdoor Unit, 208 - 230 V, 12000 Btu/hr Cooling, Steel
Samsung Smart Pearl Heat Pump Split System Outdoor Unit, Model: AR12, 208 - 230 V, 1.4/2.9/4.5 A Cooling, 1/3.9/7.5 A Heating, 39 W Condenser, 27 W Evaporator, 60 Hz, 1 ph, 3 Fan Speeds, 13600 Btu/hr Heating, 12000 Btu/hr Cooling, 270 to 420 cfm Evaporator Heating CFM Rating, 15.8 EER Rating, 28.1 SEER, 12 HSPF, Flared Connection, BLDC Rotary Compressor, R-410A Refrigerant, 15 A Fuse Rating, Inverter Drive, 46 dBA Heating Sound Level, Wall Mounting, Steel, Galvanized/Powder-Coated, Twilight White, 5 to 75 deg F Heating Operating Temperature, 14 to 115 deg F Cooling Operating Temperature, 12-3/16 in Overall Length, 34-5/8 in Overall Width, 25-1/8 in Overall Height, Additional Information: RAC Classification, 2016 Version, Inverter R-410A HP Type, Pearl Design, AR12 Model Number
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$2,057.40 / ea
Out of Stock
- Attributes
- Additional Information
- Features & Benefits
- Documents
Attributes
BrandSamsung
Additional InformationRAC Classification, 2016 Version, Inverter R-410A HP Type, Pearl Design
Amperage Rating1.4/2.9/4.5 A Cooling, 1/3.9/7.5 A Heating
ColorTwilight White
Compressor TypeBLDC Rotary
Connection TypeFlared
Cooling BTU Rating12000
Cooling Operating Temperature14 to 115
Drive TypeInverter
EER Rating15.8
FinishGalvanized/Powder-Coated
Frequency Rating60
Fuse Rating15
Heating BTU Rating13600
Heating CFM Rating270 to 420 cfm Evaporator
Heating Operating Temperature5 to 75
Heating Sound Level46
HSPF Rating12
IndustryHVAC
MaterialSteel
ModelAR12
Model NumberAR12
Mounting TypeWall
Number of Fan Speeds3
Overall Height25-1/8
Overall Length12-3/16
Overall Width34-5/8
Phase1
Power Rating39 W Condenser, 27 W Evaporator
Refrigerant TypeR-410A
SEER Rating28.1
Voltage Rating208 - 230
Additional Information
AHRI Certified|cETLus Listed|ENERGY STAR® Certified
Features & Benefits
- The indoor unit shall have Wi-Fi capability as standard for control and monitoring with the Samsung Smart Home app (Android, iOS) Outdoor unit shall provide 208/230 V power to indoor unit via 14 AWG X 3 interconnect power cable Electro-static, washable, main filter as standard accessible from the front/top of unit Indoor unit chassis shall be UL94 V0 with a galvanized steel mounting bracket The outdoor unit shall be galvanized steel with a baked on powder coated finish for durability The indoor unit shall have easy-access pipe and drain connections via access panel on front of unit for easier installation and service The indoor heat exchanger shall be mechanically bonded fin to copper tube The outdoor unit heat exchanger shall be aluminum, flat fin, micro channel The compressor shall be hermetically sealed, inverter controlled, BLDC Rotary Refrigerant flow shall be controlled by electronic expansion valve at outdoor unit The indoor fan shall be a single, antibacterial cross-flow type Automatic (motorized) vertical and horizontal swing louver
Samsung Smart Pearl AR12 AR12KSWDHWKXCV Heat Pump Split System Outdoor Unit, 208 - 230 V, 12000 Btu/hr Cooling, Steel
BrandSamsung
MFG #AR12KSWDHWKXCV
Keller #956239
