Samsung Max Heat™ CXH36SCJ AC036JXSCCH/AA Air Handler, 208-230 V, 32 A, 36000 Btu/hr Cooling, 40000 Btu/hr Heating
Samsung Max Heat™ CXH36SCJ AC036JXSCCH/AA Air Handler, 208-230 V, 32 A, 36000 Btu/hr Cooling, 40000 Btu/hr Heating
Samsung Max Heat™ Air Handler, Model: CXH36SCJ, 208-230 V, 32 A, 125 W Condenser, 1/2 hp, 60 Hz, 1 ph, 5 Fan Speeds, 40000 Btu/hr Heating, 36000 Btu/hr Cooling, 11 EER Rating, 20 SEER, 10.4 HSPF, Flared Connection, Inverter Driven, Twin BLDC Rotary Compressor, R-410A Refrigerant, 3/8 in Liquid Line, 5/8 in Suction Line, 53 dBA Heating Sound Level, 51 dBA Cooling Sound Level, Steel, Galvanized, -13 to 75 deg F Heating Operating Temperature, 23 to 115 deg F Cooling Operating Temperature, 13 in Overall Length, 37 in Overall Width, 55-7/8 in Overall Height, Additional Information: Deluxe Low Temperature Feature, Heat Pump Mode, AC0 Model Family Number, 36000 Nominal Capacity BTU Rating, R-410A Refrigerant Data: Type, Outdoor - Single Zone Heat Pump Product Type
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$10,757.88 / ea
Out of Stock
- Attributes
- Additional Information
- Features & Benefits
- Documents
Attributes
BrandSamsung
Additional InformationDeluxe Low Temperature Feature, Heat Pump Mode
Amperage Rating32
Compressor TypeInverter Driven, Twin BLDC Rotary
Connection TypeFlared
Cooling BTU Rating36000
Cooling Operating Temperature23 to 115
Cooling Sound Level51
EER Rating11
FinishGalvanized
Frequency Rating60
Heating BTU Rating40000
Heating Operating Temperature-13 to 75
Heating Sound Level53
HP Rating1/2
HSPF Rating10.4
Liquid Line Size3/8
MaterialSteel
ModelCXH36SCJ
Model Family NumberAC0
Nominal Capacity BTU Rating36000
Number of Fan Speeds5
Overall Height55-7/8
Overall Length13
Overall Width37
Phase1
Power Rating125 W Condenser
Product TypeOutdoor - Single Zone Heat Pump
Refrigerant Data: TypeR-410A
Refrigerant TypeR-410A
SEER Rating20
Suction Line Size5/8
Voltage Rating208-230
Additional Information
AHRI Certified|cETLus Intertek Listed|UL 1995
Features & Benefits
- High heating performance at -13degF Auto-restart after power loss The indoor unit shall be capable of being field convertible to downflow configuration with optional downflow conversion kit. The outdoor unit shall have a snow accumulation prevention option setting to prevent snow drifting against an idle outdoor unit. The indoor and outdoor units shall have a removable EEPROM that stores system programming information, unit name, and other data The outdoor unit shall have a night time quiet mode option to reduce operating sound during the night (automatic or manual activation with dry contact signal). The pipe connections at the outdoor unit shall be internal allowing pipes to inter the chassis through the front, right side, bottom, or back. Air handler has an air leakage of no more than 2 percent of the design air flow rate when tested in accordance with ASHRAE 193. The outdoor unit shall supply power to indoor unit via 14 AWG X 3 power wire when optional heat kits are not installed. If VHK-***A supplemental heat kits are installed, power to the heat kits must be provided from a dedicated circuit with proper overcurrent protection per NEC (refer to VHK-***A supporting documents for heat kit electrical data). The outdoor unit shall have a base pan heater as standard (150W)
