Samsung WindFree™ 3.0e AR24CSFCMWKXCV Evaporator Split System Outdoor Unit, 208 to 230 V, 13.5 A Cooling, 17.9 A Heating
Samsung WindFree™ 3.0e AR24CSFCMWKXCV Evaporator Split System Outdoor Unit, 208 to 230 V, 13.5 A Cooling, 17.9 A Heating
Samsung WindFree™ 3.0e Evaporator Split System Outdoor Unit, 208 to 230 V, 13.5 A Cooling, 17.9 A Heating, 3 kW Cooling, 4 kW Heating, 60 Hz, 1 ph, 3 Fan Speeds, 24000 Btu/hr Heating, 22000 Btu/hr Cooling, 445 to 657 cfm Heating CFM Rating, 445 to 657 cfm Cooling CFM Rating, 10.5 EER Rating, 18 SEER, 8 HSPF, Flared Connection, BLDC Rotary Compressor, R-410A Refrigerant, 1/4 in Liquid Line, 5/8 in Suction Line, 30 A Fuse Rating, Inverter Drive, 56 dBA Heating Sound Level, 56 dBA Cooling Sound Level, Steel, Galvanized/Powder-Coated, -5 to 75 deg F Heating Operating Temperature, 14 to 115 deg F Cooling Operating Temperature, 12-3/16 in Overall Length, 34-5/8 in Overall Width, 31-7/16 in Overall Height
Why Create an Account?
- Ability to track orders
- More Options & Savings
- Amazing Customer Service
$1,718.00 / ea
Out of Stock
- Attributes
- Additional Information
- Features & Benefits
- Documents
- Marketing Information
Attributes
BrandSamsung
Amperage Rating13.5 A Cooling, 17.9 A Heating
Color/FinishGalvanized/Powder-Coated
Compressor TypeBLDC Rotary
Connection TypeFlared
Cooling BTU Rating22000
Cooling CFM Rating445 to 657
Cooling Operating Temperature14 to 115
Cooling Sound Level56
Correct Item GroupSingle Zone Outdoor Units
Drive TypeInverter
EER Rating10.5
FinishGalvanized/Powder-Coated
Frequency Rating60
Fuse Rating30
Heating BTU Rating24000
Heating CFM Rating445 to 657
Heating Operating Temperature-5 to 75
Heating Sound Level56
HSPF Rating8
IndustryHVAC
Liquid Line Size1/4
MaterialSteel
Mounting TypeWall
Number of Fan Speeds3
Overall Height31-7/16
Overall Length12-3/16
Overall Width34-5/8
Phase1
Power Rating3 kW Cooling, 4 kW Heating
Refrigerant TypeR-410A
SEER Rating18
Suction Line Size5/8
Voltage Rating208 to 230
Shipping Dimensions (L x W x H)14.75" x 43.88" x 11.44"
Additional Information
AHRI Certified|cETLus Listed|UL 60335-2-40
Features & Benefits
- Outdoor unit shall provide 208/230V power to indoor unit via 14 AWG X 3 interconnect power cable The outdoor unit shall be galvanized steel with a baked-on powder coated finish for durability The heat exchangers shall be mechanically bonded fin to copper tube The compressor shall be hermetically sealed, inverter controlled, BLDC Rotary Refrigerant flow shall be controlled by an electronic expansion valve at the outdoor unit The system shall have a built in Wi-Fi adapter as standard to allow control and monitoring using the Samsung SmartThings app (Android, iOS) Dual set temperature support when connected to MWR-WG00UN Advanced Wired Controller The indoor unit shall have a simple connection for overflow detection devices or any other normally closed contact for simple unit shutdown The indoor unit shall ship with a wireless controller, holder, and batteries Wired controller options available Samsung central control compatible (MIM-R10UN accessory required) Interconnect control wire between outdoor and indoor units shall be 16AWG X 2 System energy consumption can be viewed using the Samsung SmartThings mobile app or on the indoor unit display using the included wireless controller AI (artificial intelligence) Auto Mode technology monitors factors such as indoor temperature, outdoor temperature, set temperature, and operating time to learn the patterns within your home to automatically adjust system operation to maximize occupant comfort and efficiency (Wi-Fi connection required) Eco Mode to reduce energy consumption during low demand operation Smart install mode - startup system diagnostics operation to ensure system readiness during initial operation Auto restart Auto Clean Function Freeze Wash Function 7-segment digital display on front of unit to display temperature and unit status
Documents
Marketing Information
Samsung's exclusive WindFree™* cooling technology provides users with a cool indoor climate without the discomfort of direct cold airflow. It's an advantage no other system can match.
